The PEPPERL+FUCHS NBB8-18GM60-A2-V1 is an 8 mm flush-mount inductive proximity sensor with a PNP complementary output and 4-wire M12 connector. It is designed for reliable non-contact detection of metallic objects in industrial automation. Pepperl+Fuchs specifies a 6–36 VDC operating range, 8 mm sensing distance, and -40 to +85 °C operating temperature range.

Key Technical Specifications

Pepperl+Fuchs' current product page confirms the 8 mm flush design, PNP complementary output, 6–36 VDC supply, 1350 Hz switching frequency, and IP-rated housing.

Advantages & Features

• 8 mm sensing distance for reliable metal detection.
• Flush mounting allows compact installation.
• PNP complementary output provides both normally-open and normally-closed switching signals.
• Wide 6–36 VDC operating range.
• Fast switching frequency up to 1350 Hz.
• Reverse-polarity and short-circuit protection.
• Rugged nickel-plated brass M18 housing.
• Wide -40 to +85 °C operating temperature range.
• IP65/IP66/IP67/IP68 protection for demanding industrial environments.
• 4-pin M12 connector for convenient installation.

Typical Applications

• Industrial automation
• Machine tool systems
• Conveyor and material handling equipment
• Position and end-position detection
• Parts counting and presence detection
• Packaging machinery
• Assembly and production lines

Important Precautions

• This sensor is a PNP type, so verify PLC/input compatibility before installation.
• Observe the 6–36 VDC operating voltage range.
• The specified 8 mm sensing distance applies to the reference target; actual detection distance varies with target material and size.
• Install the sensor flush and maintain appropriate spacing from surrounding metal objects.
• Use the correct 4-pin M12 connector and wiring configuration.
• Do not exceed the specified output current.
