Mitsubishi SD-T35BC DC24V 2A2B Contactor

Mitsubishi SD-T35BC DC24V 2A2B – Contactor

Specifications

• Poles: 3 main poles (3NO)
• Auxiliary Contacts: 2NO + 2NC (2A2B)
• Coil Voltage: 24 VDC
• Rated Operational Current (AC-3):
  • 35A @ 200–220 VAC
  • 32A @ 380–440 VAC
  • 26A @ 500–550 VAC
• Resistive Load (AC-1): 60A max
• Rated Motor Power (AC-3):
  • 7.5 kW @ 220–240 VAC
  • 15 kW @ 380–550 VAC
• Insulation Voltage: 690 VAC
• Mechanical Endurance: 10,000,000 operations (no load)
• Protection Class: IP20 (finger-safe terminals)
• Mounting: DIN rail or surface mount
• Dimensions (W×H×D): 75 × 89 × 123 mm
• Weight: Approx. 0.85 kg
• Certifications: CE, cULus, TUV, CCC, KCMITSUBISHI ELECTRIC

Key Features

• DC coil, no buzz: DC solenoid design, no hum, no inrush currentMITSUBISHI ELECTRIC
• Twin contacts: Higher reliability and longer lifeMITSUBISHI ELECTRIC
• Integrated terminal cover: Standard, improves safety and wiring speedMITSUBISHI ELECTRIC
• Screw-clamp terminals: With finger protection, easy wiring
• Compact size: 75 mm width, space-saving in control panels

Applications

• Motor control for conveyors, pumps, fans, machine tools
• DC-controlled systems (24 VDC coil)
• Industrial automation panels, HVAC, and general machinery
