Moxa CP-114I-DB9M Serial Interface Card

Moxa CP-114I-DB9M – Serial Interface Card

Specifications

• Bus Interface: 32-bit Universal PCIMoxa Inc.
• Number of Ports: 4 (software-selectable RS-232/422/485)
• Isolation: 2 kV optical isolation per port (RS-422/485)
• Connector: DB37 female on card; 4 x DB9 male via cable (included)
• UART: 16C550C compatible, 128-byte FIFOMoxa Inc.
• Baud Rate: 50 bps to 921.6 kbpsMoxa Inc.
• Data Bits: 5, 6, 7, 8Moxa Inc.
• Stop Bits: 1, 1.5, 2Moxa Inc.
• Parity: None, Even, Odd, Space, MarkMoxa Inc.
• Flow Control: None, RTS/CTS, XON/XOFFMoxa Inc.
• Max Devices (RS-485): 31 nodes, 1.2 km distance
• OS Support: Windows, Linux, UNIX
• Operating Temperature: 0 °C to +55 °CMOXA
• Dimensions: 160 × 120 mm

Key Features

• 4 independent isolated ports: Protects PC from surge/ESD in industrial environments
• Multi-protocol support: Each port can be set to RS-232, RS-422, or RS-485
• High-speed communication: Up to 921.6 kbps for demanding data acquisitionMoxa Inc.
• Easy integration: Comes with DB9M cable for direct connection to serial devices
• Reliable drivers: Broad OS compatibility for seamless system integration

Applications

• Industrial automation, SCADA, data acquisition
• Connecting PLCs, meters, sensors, and serial devices to PC
• Long-distance RS-485 networks in factory environments
