Honeywell XP6-C I/O Module

Product Overview

The Honeywell XP6-C I/O Module (also known as NOTIFIER XP6-C Six Circuit Supervised Control Module) is an intelligent addressable control output module used in Honeywell fire alarm systems. It provides six supervised output circuits for controlling external notification devices such as horns, strobes, bells, speakers, and other alarm equipment.

The XP6-C communicates with compatible fire alarm control panels through the Signaling Line Circuit (SLC) and allows the control panel to activate external devices while continuously monitoring field wiring for faults.

Main Specifications

• Manufacturer: Honeywell / NOTIFIER
• Model: XP6-C
• Product Type:
  • Intelligent Addressable I/O Module
  • Six Circuit Supervised Control Module
  • Fire Alarm Output Interface Module
• Application:
  • Fire alarm notification control
  • External device activation
  • Supervised output switching
• Communication:
  • FlashScan® / CLIP protocol
• Mounting:
  • CHS-6 chassis
  • BB-XP cabinet
  • CAB-3 / CAB-4 series cabinets

Technical Specifications

Output Channels

• Number of Outputs:
  • 6 addressable supervised output circuits
• Output Types:
  • Notification Appliance Circuit (NAC)
  • Speaker circuit
  • Telephone circuit
• Class Operation:
  • Class B (Style Y)
  • Class A (Style Z) with configuration
• Address Range:
  • First module address: 01–154
  • Remaining points automatically assigned to next five addresses

Electrical Specifications

Functional Features

The XP6-C provides:

• Six individually addressable control outputs
• Continuous wiring supervision
• Short-circuit monitoring protection
• LED status indication for each output point
• External power supply connection
• Address setting through rotary switches
• Compatible with intelligent fire alarm panels

Protection & Diagnostics

Built-in functions include:

• Open circuit detection
• Short circuit detection
• Output fault monitoring
• Point status indication
• Communication fault monitoring

The module can prevent activation of circuits with detected short-circuit conditions to protect connected alarm devices and power supplies.

Features & Advantages

• Original Honeywell NOTIFIER intelligent fire alarm module
• Provides multiple supervised control outputs in one compact unit
• Reduces system wiring complexity
• Improves alarm system reliability
• Supports distributed fire notification control
• Easy installation and replacement
• Compatible with large-scale addressable fire alarm networks

Applications

Used in:

• Commercial buildings
• Industrial plants
• Power stations
• Hospitals
• Data centers
• Warehouses
• Transportation facilities

Typical applications:

• Fire alarm horn/strobe control
• Emergency notification systems
• Speaker control systems
• Alarm annunciation systems
• Building safety systems
