Honeywell 05701-A-0121 Gas Detection Module

Product Overview

The Honeywell 05701-A-0121 is System 57 Engineering Interface Software, used for configuration, commissioning, maintenance, and diagnostics of Honeywell System 57 gas detection control systems. It provides a PC-based engineering interface for setting parameters, viewing system status, configuring gas channels, and performing maintenance operations.

Note: This model is not a gas detection I/O module itself. The 05701-A-0121 is an engineering interface software package/accessory for System 57 gas detection controllers. The actual gas control cards are models such as 5701/5704 series channel control cards.

Main Specifications

• Manufacturer: Honeywell Analytics
• Model: 05701-A-0121
• System: Honeywell System 57 Gas Detection System
• Product Type:
  • Engineering Interface Software
  • Gas Detection System Configuration Tool
  • Maintenance & Diagnostic Software
• Application:
  • System configuration
  • Alarm parameter setup
  • Gas channel monitoring
  • System diagnostics

Functions & Features

Configuration Functions

Supports:

• Gas channel configuration
• Alarm level setting
• Sensor parameter setup
• Input/output configuration
• System parameter adjustment

Monitoring Functions

Provides:

• Real-time gas channel status display
• Alarm status monitoring
• Fault diagnosis
• System event viewing
• Maintenance information

Maintenance Functions

Includes:

• System commissioning
• Troubleshooting assistance
• Parameter backup and restoration
• Controller maintenance support

Compatible System

Compatible with:

• Honeywell Analytics System 57 Gas Detection Controllers
• 5701 Single Channel Gas Control Systems
• 5704 Four Channel Gas Control Systems

System 57 supports inputs from:

• Flammable gas detectors
• Toxic gas detectors
• Oxygen detectors
• 4–20 mA gas transmitters

Features & Advantages

• Original Honeywell System 57 engineering accessory
• Simplifies gas detection system commissioning
• Improves troubleshooting efficiency
• Allows convenient PC-based configuration
• Reduces maintenance time
• Supports industrial gas safety system management

Applications

Used in:

• Oil & gas facilities
• Chemical plants
• Refineries
• Power generation plants
• Offshore platforms
• Industrial safety monitoring systems

Typical applications:

• Combustible gas monitoring
• Toxic gas detection
• Oxygen deficiency monitoring
• Safety alarm systems
