Honeywell TC-PRR021 Redundancy Module

Basic Overview

Distinction Reminder

Core Electrical & Hardware Parameters

1. Power Specifications

• Auxiliary supply: 24VDC, operating current 90mA
• Internal bus power: 5V (1.0A) / 3.3V (0.75A)
• Dielectric isolation: 1500VAC isolation between sync bus and backplane
• Typical power consumption: ~5W, max 8W

2. Rack Slot & Mechanical

• Occupies 2 slots in C200 standard rack chassis
• Dimension: 160 × 90 × 60 mm, net weight 0.46kg
• Hot-swap support: Replace module online without rack power cut
• Front panel LED indicators: Power, Sync Link, Active/Standby, Fault alarm
• Dedicated high-speed redundancy port, connected by proprietary sync cable to pair another TC-PRR021

3. Environmental & Reliability

• Operating temp: 0℃ ~ +60℃; storage: -40℃ ~ +85℃
• Humidity: 5%–95% RH non-condensing
• Vibration resistance: 5g (10–500Hz), shock resistance 20g
• MTBF ≥150,000 hours, CE/UL industrial certified

Core Redundancy Working Functions

1. Real-time full mirror data synchronization

   Continuously synchronize control logic, PID parameters, I/O status, alarm logs, historical trend data between primary and standby C200 CPU, keep standby controller running state fully consistent with master.
2. Millisecond-level bumpless automatic failover

   When primary CPU fails (power loss, hardware breakdown, communication loss), the module triggers seamless switchover within <10ms; process output maintains stable value without fluctuation, no production interruption.
3. Dual-side mutual health heartbeat monitoring

   Two paired TC-PRR021 modules transmit heartbeat signals mutually, instantly report sync disconnection, module failure to DCS operation station.
4. Manual forced switchover support

   Engineers can manually switch master/standby role on HMI for online equipment maintenance without stopping process.
5. Complete fault event logging

   Record switchover time, fault root cause, module running status for post-failure analysis.

Complete Redundant System Matching Configuration

• 2 × TC-PRR021 redundancy modules
• 2 × C200 controller CPU
• Special dedicated redundancy sync cable
• Dual redundant power supply modules

Key Advantages

1. High-speed isolated sync bus, strong anti-EMI performance, stable operation in chemical, power plant heavy interference environments
2. Zero-disturbance switching, suitable for continuous production processes that cannot halt
3. Online hot-swap design, reduce maintenance downtime
4. Independent front fault diagnosis LEDs, fast on-site fault location
5. Conformal coated circuit optional, adaptable to coastal, high-humidity corrosive industrial cabinets

Typical Application Scenarios

• Petrochemical refinery, natural gas processing plant core process control racks
• Thermal power boiler, turbine DCS control systems
• Chemical reactor, hazardous material storage SIS auxiliary control loops
• Large sewage treatment, water supply central DCS cabinets
• Fertilizer, coal chemical continuous production critical control units
• All industrial production lines requiring high availability and zero unplanned shutdown risk
