                                      • GE TQD32225WL Circuit Breaker

                                        Overview

                                        TQD32225WL is a compact molded case circuit breaker (MCCB) from GE Q-Line TQD series, built for 3-phase 240V commercial and light industrial power distribution. The suffix WL stands for integrated line & load lug terminals for direct cable connection. It adopts fixed thermal-magnetic trip design to offer overload and short-circuit protection for main feeders, HVAC systems and motor loads.


                                        GE TQD32225WL Breaker



                                        Front View



                                        Specifications

                                        • Rated current: 225A; Poles: 3; Rated voltage: 240V AC, 50/60Hz
                                        • Interrupt capacity: 10kA @ 240V AIC
                                        • Trip type: Fixed LI thermal-magnetic trip (long-time overload + instantaneous short-circuit trip), non-interchangeable trip unit
                                        • Mounting: Bolt-on fixed installation, feed-thru wiring design
                                        • Terminals: Copper/aluminum lugs, compatible with 1 AWG to 300 kcmil cables
                                        • Dimension: 6-9/16"H × 4-1/8"W × 2-5/8"D
                                        • Operating temperature: 10°C ~ 50°C; HACR rated for heating & air conditioning loads
                                        • Standard certification: UL Listed (File E11592)

                                        Key Functions

                                        1. Thermal protection: Trips automatically under long-term overload to prevent cable insulation overheat
                                        2. Magnetic instantaneous trip: Fast cut-off within milliseconds when severe short-circuit occurs
                                        3. 3-pole common trip: All three poles disconnect simultaneously to avoid single-phase operation risks
                                        4. Lug terminals simplify wiring for large cross-section power cables; supports reverse feed installation
                                        5. Rigid molded plastic housing provides insulation and mechanical impact resistance for cabinet deployment

                                        Compatible Equipment

                                        • GE Q-Line series distribution panelboards and MCC enclosures
                                        • 3-phase industrial fans, pumps, compressors and central air conditioning units
                                        • Commercial building main power feeders and sub-circuit distribution branches

                                        Applications

                                        Commercial & light industrial power distribution:
                                        • Shopping mall, office building main power panels
                                        • Factory HVAC, refrigeration and pump control cabinets
                                        • Small manufacturing workshop three-phase load protection
                                        • Retail center and warehouse electrical distribution systems

The structure and details of the product：
