                            • • • • • • • GE THED136015WL Circuit Breaker

                                          Overview

                                          THED136015WL is a GE molded case circuit breaker (MCCB) from the THED series for low-voltage power distribution. The model is a 3-pole unit rated 15A, with WL suffix indicating line and load lug terminals for large cable wiring. It delivers overload and short-circuit protection for general industrial and commercial 3-phase loads, widely used in control panels, machinery and building distribution systems.

                                          Specifications

                                          • Poles: 3 poles
                                          • Rated current: 15 A
                                          • Rated voltage: 600 V AC, 50/60 Hz
                                          • Thermal-magnetic fixed trip unit for overload & short-circuit protection
                                          • Bolt-on mounting structure, lug terminal design for copper/aluminum conductors
                                          • Standard industrial cabinet operating temperature range
                                          • UL listed safety certification, suitable for general machinery and power distribution

                                          Key Functions

                                          1. Thermal delay trip to protect cables and equipment from sustained overload heating damage
                                          2. Instantaneous magnetic trip to quickly cut power during short circuit faults
                                          3. Common trip three-pole design, all phases disconnect at once to avoid single-phase operation hazards
                                          4. Lug terminals simplify wiring of thick power cables, support forward and reverse feed wiring
                                          5. High-strength insulating housing prevents arc leakage and mechanical impact damage inside electrical cabinets

                                          Compatible Equipment

                                          • GE low-voltage distribution cabinets and motor control centers
                                          • Small three-phase motors, pumps, fans, compressors and light industrial equipment
                                          • Commercial building branch distribution circuits

                                          Applications

                                          General commercial and light industrial low-voltage power protection:
                                          • Factory machinery control cabinets
                                          • Office and shopping mall electrical distribution panels
                                          • HVAC, water pump and small motor load protection

The structure and details of the product：
