                                            • GE MMII-PD-1-2-240 Motor Management Relay

                                              Overview

                                              MMII-PD-1-2-240, also called MM2 Motor Manager II, is a full-featured microprocessor-based motor protection & control relay from GE Multilin. PD stands for panel-mount with built-in LCD display; the digits 1 and 2 represent two full optional function packages, and 240 means 240 VAC control power supply. It integrates complete protection, local operation, power metering and communication for low-voltage AC motors, widely installed in intelligent Motor Control Centers (MCC).

                                              Specifications

                                              • Power supply: 240 VAC control power
                                              • Mounting: Panel flush mount with front 2-line 40-character LCD and physical operation keypad
                                              • Digital I/O: 6 fixed control inputs + 10 programmable optical isolated digital inputs; dual contactor control relays + 2 extra programmable auxiliary relays
                                              • Analog interfaces: 4–20mA process input, PTC/NTC thermistor winding temperature input, single VT voltage input
                                              • Communication: RS485 Modbus RTU, baud rate 1200–19200 bps
                                              • Operating temperature: 0°C ~ +60°C; cabinet indoor installation only
                                              • Configuration software: GE EnerVista MMII for parameter setting, fault analysis and data backup
                                              • Full set of built-in LED status indicators for run, stop, trip, alarm and communication status

                                              Key Functions

                                              1. Comprehensive motor protection

                                                 Covers thermal overload, locked rotor stall, single-phase loss, phase unbalance, ground fault, over/under voltage, undercurrent and winding overheat via thermistor monitoring.
                                              2. Dual-contactor intelligent control

                                                 Supports two-speed motors, star-delta starters and reversing motor logic with built-in timing functions; realizes local manual start/stop and remote auto operation modes.
                                              3. Power & equipment monitoring

                                                 Measures 3-phase current, voltage, kW, kWh and power factor; records motor running hours, startup times, pre-trip data and fault event logs for predictive maintenance.
                                              4. Process signal interaction

                                                 Collects 4–20mA analog signals from field transmitters to implement interlock logic for pumps, fans and compressors.
                                              5. Remote data transmission

                                                 Uploads real-time motor status, alarms and metering data to SCADA/HMI systems via Modbus communication.

                                              Compatible Equipment

                                              • Low-voltage MCC cabinets, AC contactors and circuit breakers
                                              • Motor winding PTC/NTC temperature sensors, 4–20mA field transmitters
                                              • GE EnerVista configuration software, upper-level DCS and HMI monitoring workstations
                                              • CT/PT secondary wiring circuits for motor power measurement

                                              Applications

                                              Industrial low-voltage motor control scenarios:

                                              • Petrochemical plant pumps, fans and compressors
                                              • Thermal power plant auxiliary motor MCC panels
                                              • Water treatment and wastewater process motors
                                              • Mining, cement and manufacturing workshop motor control centers

The structure and details of the product：
