GE IC755CSW07CDA Industrial HMI Panel

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

                                                                              GE IC755CSW07CDA QuickPanel+ 7" Industrial HMI Touch Panel



                                                                              Overview

                                                                              IC755CSW07CDA is Emerson (formerly GE Intelligent Platforms) QuickPanel+ series 7-inch industrial operator touch screen, matched with PACSystems RX3i PLC system. It adopts projected capacitive multi-touch widescreen, built-in Windows Embedded Compact 7 OS, integrates high-performance ARM processor and rich communication ports, used for on-site process data monitoring, equipment manual operation, alarm display and production data recording in power, chemical, water treatment and machinery automation projects.

                                                                              Core Hardware Specifications

                                                                              Display & Touch

                                                                              • Screen: 7-inch widescreen TFT color LCD
                                                                              • Resolution: WVGA 800 × 480
                                                                              • Touch type: Projected capacitive multi-touch, supports glove operation
                                                                              • Front panel protection: IP65 / NEMA 4X dustproof and waterproof, GE logo standard bezel

                                                                              Performance & Memory

                                                                              • Processor: Freescale i.MX535 1GHz ARM Cortex-A8 with 2D/3D GPU
                                                                              • RAM: 512MB DDR2 SDRAM
                                                                              • Storage: 256MB SLC industrial NAND Flash + 512KB SRAM
                                                                              • System OS: Windows Embedded Compact 7

                                                                              Communication & Interfaces (Rear Terminals)

                                                                              1. LAN: 1 × 10/100Mbps Ethernet port (Modbus TCP, EGD, SRTP, OPC UA)
                                                                              2. COM: RS232 serial port (Modbus RTU, SNP, connects GE RX3i PLC serial modules)
                                                                              3. USB: 3 × USB2.0 (data upload/download, mouse, U disk program update)
                                                                              4. SDHC card slot: External storage expansion
                                                                              5. Power: 24VDC DC power supply terminal block

                                                                              Environmental & Mechanical

                                                                              • Power supply: 24VDC (18–30VDC allowable range)
                                                                              • Operating temperature: -20℃ ~ +60℃; Humidity 0–95% RH non-condensing
                                                                              • Overall dimension: 224 × 163 × 44 mm (W×H×D)
                                                                              • Weight: ~0.8kg
                                                                              • Installation: Standard cabinet embedded panel mounting, matching dedicated mounting brackets IC755ACC07MNT

                                                                              Supported Communication Protocols

                                                                              • GE proprietary: EGD, SRTP (interconnection with RX3i PLC IC695CPE305 series CPU)
                                                                              • General industrial: Modbus TCP Client/Server, Modbus RTU, OPC UA
                                                                              • Time synchronization: SNTP unified clock synchronization
                                                                              • Compatible with third-party PLCs, protection IEDs, flow meters and vibration monitors

                                                                              Key Functions

                                                                              1. Real-time process visualization

                                                                                 Display analog measurement values (temperature, pressure, flow), digital equipment running status, real-time trend curves and equipment animation screens.
                                                                              2. Local manual operation control

                                                                                 Touch screen buttons realize valve switch, pump start/stop, setpoint adjustment and equipment interlock operation.
                                                                              3. Alarm management system

                                                                                 Real-time fault alarm pop-up, historical alarm record storage, classified alarm query and fault time stamp recording.
                                                                              4. Production data logging

                                                                                 Store operation parameters, yield data to local flash or SD card, support U disk export for MES upper system upload.
                                                                              5. Multi-language human-machine interface

                                                                                 Built-in multi-language switching function, applicable to cross-regional factory production lines.
                                                                              6. Seamless linkage with RX3i PLC

                                                                                 Directly read/write RX3i CPU register tags via Ethernet or serial port, coordinate with IC695ETM001 / IC695ECM850 communication modules for stable data interaction.
                                                                              7. Offline program maintenance

                                                                                 USB disk offline download HMI project without PC on-site wiring; support remote screen viewing and remote debugging via Ethernet.

                                                                              Matching Compatible Equipment

                                                                              • RX3i PLC full set: IC695CHS007/CHS012 backplane, IC695CPE305 CPU, IC695PSD140 power supply
                                                                              • Communication modules: IC695ETM001 Ethernet, IC695CMM004 serial, IC695ECM850 IEC61850 module
                                                                              • Programming software: Proficy Machine Edition (HMI drawing, tag configuration, project download)
                                                                              • Supporting accessories: IC755ACC07MNT mounting bracket, IC755ACCBATT backup lithium battery, screen protective film

                                                                              Typical Industrial Applications

                                                                              • Thermal power plant turbine auxiliary PLC control cabinet local operation panel
                                                                              • Petrochemical continuous production process monitoring & operation station
                                                                              • Water treatment pump station, sewage plant centralized touch control terminal
                                                                              • Packaging, metallurgy, mining machinery equipment on-site operation screen
                                                                              • Wind & solar new energy grid-connected station secondary monitoring system
                                                                              • Old GE Series 90-30 PLC renovation supporting HMI upgrade
