                                                                                                                                                                                                                                            • GE IC695ACC400 Energy Pack

                                                                                                                                                                                                                                              Product Description

                                                                                                                                                                                                                                              The GE IC695ACC400 is an RX3i CPU Energy Pack designed for the GE PACSystems RX3i automation platform. It is used with the IC695CPE305 and IC695CPE310 CPU modules to provide temporary backup power during a power failure, allowing the CPU to safely save user memory to non-volatile Flash memory. This eliminates the need for a traditional battery backup while protecting critical application data.

                                                                                                                                                                                                                                              Detailed Specifications

                                                                                                                                                                                                                                              Parameter	Specification
                                                                                                                                                                                                                                              Manufacturer	GE Intelligent Platforms / Emerson
                                                                                                                                                                                                                                              Model	IC695ACC400
                                                                                                                                                                                                                                              Product Type	CPU Energy Pack
                                                                                                                                                                                                                                              Platform	PACSystems RX3i
                                                                                                                                                                                                                                              Compatible CPUs	IC695CPE305, IC695CPE310
                                                                                                                                                                                                                                              Function	Backup Power for Memory Save
                                                                                                                                                                                                                                              Input Power	24 VDC (from CPU via cable)
                                                                                                                                                                                                                                              Connection Cable	IC695CBL001 (0.91 m / 3 ft)
                                                                                                                                                                                                                                              Mounting	Left side of RX3i module
                                                                                                                                                                                                                                              Dimensions	140 × 124 × 25.4 mm
                                                                                                                                                                                                                                              Operating Temperature	0°C to 60°C
                                                                                                                                                                                                                                              Compliance	RoHS



                                                                                                                                                                                                                                              Advantages & Features

                                                                                                                                                                                                                                              • Provides temporary backup power during power loss
                                                                                                                                                                                                                                              • Allows CPU to save RAM contents to non-volatile Flash memory
                                                                                                                                                                                                                                              • Eliminates the need for battery-backed memory
                                                                                                                                                                                                                                              • Charges automatically from the RX3i 24 VDC supply
                                                                                                                                                                                                                                              • Compact side-mounted design that does not occupy a backplane slot
                                                                                                                                                                                                                                              • Enhances controller reliability and data integrity
                                                                                                                                                                                                                                              • Easy installation using the IC695CBL001 cable



                                                                                                                                                                                                                                              Applications

                                                                                                                                                                                                                                              • GE PACSystems RX3i PLC Systems
                                                                                                                                                                                                                                              • Industrial Automation
                                                                                                                                                                                                                                              • Process Control
                                                                                                                                                                                                                                              • Manufacturing Equipment
                                                                                                                                                                                                                                              • Power Generation
                                                                                                                                                                                                                                              • Water & Wastewater Treatment
                                                                                                                                                                                                                                              • Oil & Gas Facilities

                                                                                                                                                                                                                                              Precautions

                                                                                                                                                                                                                                              • Compatible only with the IC695CPE305 and IC695CPE310 CPU modules.
                                                                                                                                                                                                                                              • Use the IC695CBL001 connection cable for installation.
                                                                                                                                                                                                                                              • Mount the Energy Pack on the left side of the RX3i module.
                                                                                                                                                                                                                                              • Allow the Energy Pack to fully charge after installation.
                                                                                                                                                                                                                                              • Disconnect system power before installation or replacement.

The structure and details of the product：
