                                                                                                                                                                                            • GE IC200CHS002 Base Module

                                                                                                                                                                                              Product Description

                                                                                                                                                                                              GE IC200CHS002 is a VersaMax Series Box-Style I/O Carrier Module (Base Module) designed for GE Fanuc VersaMax PLC systems. It provides the mechanical mounting, electrical connection, and backplane communication interface for VersaMax I/O modules.

                                                                                                                                                                                              Unlike a CPU or I/O signal module, the IC200CHS002 itself does not process control logic or provide signal conversion. It serves as the mounting base and wiring interface where compatible VersaMax I/O modules are installed.

                                                                                                                                                                                              ---

                                                                                                                                                                                              Technical Parameters

                                                                                                                                                                                              • Brand: GE Fanuc / Emerson Automation
                                                                                                                                                                                              • Model: IC200CHS002
                                                                                                                                                                                              • Series: VersaMax
                                                                                                                                                                                              • Product Type: I/O Carrier Base Module
                                                                                                                                                                                              • Carrier Style: Box-Style Terminal Carrier
                                                                                                                                                                                              • Function: I/O module mounting & field wiring connection
                                                                                                                                                                                              • Number of Terminals: 36 terminals
                                                                                                                                                                                                • A1–A18
                                                                                                                                                                                                • B1–B18
                                                                                                                                                                                              • Terminal Type: IEC box-style screw terminals
                                                                                                                                                                                              • Mounting Type: DIN Rail mounting
                                                                                                                                                                                              • Installation Orientation: Horizontal mounting
                                                                                                                                                                                              • Voltage Rating: 0–264 VAC
                                                                                                                                                                                              • Current Rating:
                                                                                                                                                                                                • 2 A per point
                                                                                                                                                                                                • 8 A per power/ground segment
                                                                                                                                                                                              • Compatible Wire Size: AWG #14–#22
                                                                                                                                                                                              • Weight: Approx. 0.31 kg
                                                                                                                                                                                              • Compatible System: GE Fanuc / Emerson VersaMax PLC platform

                                                                                                                                                                                              ---

                                                                                                                                                                                              Advantages & Features

                                                                                                                                                                                              • Original GE Fanuc VersaMax I/O carrier component
                                                                                                                                                                                              • Provides secure mounting for VersaMax I/O modules
                                                                                                                                                                                              • Integrated field wiring terminals simplify installation
                                                                                                                                                                                              • Supports quick module replacement and maintenance
                                                                                                                                                                                              • Compact DIN rail mounting design
                                                                                                                                                                                              • Reliable backplane communication connection
                                                                                                                                                                                              • Suitable for modular industrial automation systems

                                                                                                                                                                                              ---

                                                                                                                                                                                              Applications

                                                                                                                                                                                              • GE VersaMax PLC control systems
                                                                                                                                                                                              • Factory automation equipment
                                                                                                                                                                                              • Machine control systems
                                                                                                                                                                                              • Process monitoring systems
                                                                                                                                                                                              • Packaging machinery
                                                                                                                                                                                              • Manufacturing production lines
                                                                                                                                                                                              • Industrial control cabinets
                                                                                                                                                                                              • Remote I/O stations

                                                                                                                                                                                              ---

                                                                                                                                                                                              Notes

                                                                                                                                                                                              • IC200CHS002 is an I/O carrier/base module, not a CPU module or analog/digital I/O module.
                                                                                                                                                                                              • Requires compatible VersaMax I/O modules installed on the carrier.
                                                                                                                                                                                              • Confirm module compatibility before replacement.
                                                                                                                                                                                              • Check terminal wiring and mounting orientation during installation.
                                                                                                                                                                                              • Ensure power is removed before replacing or servicing the carrier.
                                                                                                                                                                                            •

The structure and details of the product：
