              • Beckhoff EL6632 PROFINET Communication Terminal

                Product Type: EtherCAT PROFINET IRT Controller Terminal
                Model: EL6632
                Manufacturer: Beckhoff Automation
                Function: EtherCAT-to-PROFINET communication interface

                The Beckhoff EL6632 is a 2-port PROFINET IRT controller terminal that connects an EtherCAT system with PROFINET IO devices. It supports both PROFINET RT and IRT, with Conformance Class C and extensive diagnostic functions.

                Technical Specifications

                Parameter	Specification
                Model	EL6632
                Technology	PROFINET IO
                Function	PROFINET RT / IRT Controller
                Ethernet Ports	2 × RJ45
                Interface	100BASE-TX
                Max. IRT Devices	Up to 5
                Max. RT Devices	Up to 15
                Minimum IRT Cycle	500 μs
                Minimum RT Cycle	1 ms
                Conformance Class	C
                Cable Length	Up to 100 m
                Max. Process Data	1 kB input / 1 kB output
                E-bus Current	Approx. 400 mA
                Electrical Isolation	500 V E-bus/Ethernet
                Configuration	Via EtherCAT Master
                Operating Temperature	0 to +55°C
                Protection Rating	IP20
                Mounting	35 mm DIN rail
                Dimensions	Approx. 26 × 100 × 52 mm
                Weight	Approx. 75 g



                Advantages & Features

                • PROFINET RT & IRT Support: Enables real-time and isochronous real-time communication.
                • High-Speed Communication: Supports IRT cycles down to 500 μs.
                • Dual RJ45 Ports: Suitable for PROFINET line topology.
                • Conformance Class C: Provides advanced PROFINET functionality.
                • EtherCAT Integration: Connects PROFINET devices to an EtherCAT control system.
                • Built-in Diagnostics: Status LEDs and network diagnostic functions simplify troubleshooting.
                • Compact Design: Space-saving EtherCAT terminal format for industrial control cabinets.
                • Flexible Device Connectivity: Supports up to 5 IRT or 15 RT devices depending on cycle time and data volume.

                Typical Applications

                • Industrial automation
                • Factory automation
                • PLC and I/O systems
                • Motion control
                • Machine automation
                • PROFINET device integration
                • EtherCAT–PROFINET gateway applications
                • Manufacturing production lines
                • Process control systems

The structure and details of the product：
