BECKHOFF EL5152 EtherCAT Encoder Interface Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

                                                              • Product Overview

                                                                • Brand: BECKHOFF
                                                                • Model: EL5152
                                                                • Product Type: EtherCAT Encoder Interface Terminal
                                                                • Series: EtherCAT Terminals
                                                                • Function: Incremental encoder signal acquisition
                                                                • Channels: 2
                                                                • Communication: EtherCAT
                                                                • Mounting: DIN rail
                                                                • Power Supply: 24 V DC system supply

                                                                Key Technical Specifications

                                                                • Encoder Type: Incremental encoder
                                                                • Inputs: 2 encoder interfaces
                                                                • Input Signals: A, B and zero/reference pulse
                                                                • Signal Evaluation: 5 V TTL / RS422-compatible differential signals
                                                                • Frequency: Up to approx. 100 kHz, depending on operating mode
                                                                • Position Resolution: 32-bit counter
                                                                • Synchronization: Distributed Clocks supported
                                                                • Diagnostics: Channel and EtherCAT status indication
                                                                • Installation: Standard EtherCAT terminal system

                                                                Advantages & Features

                                                                • Dual-channel encoder signal acquisition
                                                                • High-resolution position measurement
                                                                • Fast EtherCAT communication
                                                                • Supports precise synchronized motion applications
                                                                • 32-bit position counters provide a wide measurement range
                                                                • Compact DIN-rail design
                                                                • Easy integration with Beckhoff TwinCAT control systems

                                                                Applications

                                                                • Motion Control
                                                                • Servo Systems
                                                                • Robotics
                                                                • CNC Machinery
                                                                • Packaging Machinery
                                                                • Conveyor Systems
                                                                • Position and Speed Measurement
                                                                • Factory Automation

                                                                Important Notes

                                                                • Verify encoder signal type and voltage level before connection.
                                                                • Confirm encoder wiring for A/B/Z signals.
                                                                • Check maximum input frequency for the selected operating mode.
                                                                • Ensure correct EtherCAT master and TwinCAT configuration.
                                                                • Use proper shielding and grounding for encoder cables.
                                                                • Disconnect power before installation or wiring changes.
