                                                        • BECKHOFF CX1100-0001 Embedded PC Power Supply Module

                                                          The BECKHOFF CX1100-0001 is a 24 VDC Power Supply Module for CX1010/CX1020 Embedded PC systems. Unlike the CX1100-0004, it has no E-Bus or K-Bus interface and is primarily used to supply power to the CX system. It also provides an LCD display, navigation functions and 8 kB NOVRAM.

                                                          Key Technical Specifications

                                                          Parameter	Specification
                                                          Brand	BECKHOFF
                                                          Model	CX1100-0001
                                                          Product Type	Embedded PC Power Supply Module
                                                          Compatible Systems	CX1010 / CX1020 / CX1030
                                                          Input Voltage	24 VDC (-15%/+20%)
                                                          E-Bus	No
                                                          K-Bus	No
                                                          IP-Link	No
                                                          NOVRAM	8 kB
                                                          Display	Illuminated FSTN, 2 × 16 characters
                                                          Diagnostic LED	PWR
                                                          Connection	5-pin pluggable connector
                                                          Max. Power Consumption	2.5 W
                                                          Dimensions	45 × 100 × 91 mm
                                                          Weight	Approx. 180 g
                                                          Operating Temperature	0 to +55°C
                                                          Storage Temperature	-25 to +85°C
                                                          Protection	IP20

                                                          Beckhoff specifies that the CX1100-0001 has no I/O interface; other CX system components receive their power through the internal PC/104 system bus.

                                                          Features & Advantages

                                                          • 24 VDC power supply for CX Embedded PC systems
                                                          • Integrated 8 kB NOVRAM for fail-safe process-data storage
                                                          • Built-in 2 × 16-character illuminated LCD
                                                          • Compact modular design
                                                          • Field-replaceable power supply
                                                          • No additional I/O bus interface, providing a simple power-supply configuration

                                                          Typical Applications

                                                          • Beckhoff CX1010/CX1020 Embedded PC systems
                                                          • Industrial automation
                                                          • Machine control
                                                          • PLC systems
                                                          • Control cabinet applications
                                                          • Legacy TwinCAT automation systems
                                                        •
