                                                          • BECKHOFF CX1020-0000 Embedded PC

                                                            The BECKHOFF CX1020-0000 is a CX1020 Embedded PC CPU Module for industrial automation and control applications. It features a 1 GHz Intel Celeron M ULV processor, 256 MB DDR RAM, dual 10/100 Mbit/s Ethernet ports, and a CompactFlash interface. The -0000 version is supplied without an operating system and without TwinCAT Runtime.

                                                            Key Technical Specifications

                                                            Parameter	Specification
                                                            Brand	BECKHOFF
                                                            Model	CX1020-0000
                                                            Product Type	Embedded PC / CPU Module
                                                            Series	CX1020
                                                            Processor	Intel Celeron M ULV
                                                            CPU Speed	1 GHz
                                                            Main Memory	256 MB DDR-RAM
                                                            Flash Memory	64 MB CompactFlash
                                                            Ethernet	2 × RJ45 10/100 Mbit/s
                                                            Ethernet Switch	Integrated
                                                            Operating System	None
                                                            TwinCAT Runtime	None
                                                            System Bus	16-bit ISA / PC104
                                                            Power Supply	Via CX1100-000x power supply module
                                                            Cooling	Passive
                                                            Dimensions	96 × 112 × 99 mm
                                                            Weight	Approx. 550 g
                                                            Operating Temperature	0 to +50°C
                                                            Storage Temperature	-25 to +85°C
                                                            Protection	IP20



                                                            Features & Advantages

                                                            • 1 GHz Intel Celeron M ULV processor
                                                            • Compact industrial Embedded PC design
                                                            • Dual Ethernet ports with integrated switch
                                                            • 256 MB DDR memory
                                                            • CompactFlash storage
                                                            • Fanless/passive cooling
                                                            • Modular CX system architecture
                                                            • Supports PLC and motion-control applications when configured with appropriate software

                                                            Typical Applications

                                                            • Industrial PLC control
                                                            • Machine automation
                                                            • Motion control
                                                            • Manufacturing systems
                                                            • Industrial Ethernet networking
                                                            • Beckhoff TwinCAT control systems

The structure and details of the product：
