Beckhoff CP6209 Panel PC

Beckhoff CP6209

Panel PC (Economy Built‑in HMI/IPC)

Specifications

• Display: 15‑inch TFT, 1024×768 (XGA), 4:3, touchscreen option
• Processor: Intel Celeron (2‑core) up to Core i7 (8‑core)
• Memory: DDR4‑RAM (4 GB standard, up to 64 GB)
• Storage: CFast card / 2.5” HDD/SSD; optional RAID 1
• Motherboard: 3.5” integrated form factor
• Ethernet: 2×100/1000BASE‑T (independent, EtherCAT‑capable)
• I/O: 4×USB 3.0, 1×RS232, 1×DVI, 2×PCIe slots
• Power: 24 V DC (22–30 V), 5.5 A max; optional integrated UPS
• Cooling: Speed‑controlled fan cartridge (dual ball bearings)
• Protection: Front IP65, rear IP20
• Temperature: 0°C to +55°C (operating)
• OS: Windows 10/11 IoT Enterprise, TwinCAT compatible
• Mounting: Cabinet front panel installation
• Weight: ~3.5 kg

Key Features

• All‑in‑One IPC+HMI: Combines industrial PC, display, and touch in one unit
• EtherCAT Master Ready: Dual Ethernet ports for control and EtherCAT networks
• Rugged Design: IP65 front for dust/water resistance; wide temp range
• Scalable Performance: From basic Celeron to high‑end Core i7 for complex tasks
• Hot‑Swap Storage: CFast/SSD options for high reliability; no moving parts
• Integrated UPS Option: Protects data during power outages

Applications

• Machine HMI & Control: Embedded control cabinet operator interface
• EtherCAT Controllers: Compact, powerful EtherCAT master for machine automation
• Factory Visualization: SCADA, data acquisition, and IoT gateway
• Process & Packaging: High‑reliability HMI/IPC for continuous operation
