                                                • Beckhoff AX5112-0000-0200 Servo Drive Module

                                                  Product Type: Digital Compact Servo Drive
                                                  Model: AX5112-0000-0200
                                                  Series: AX5000
                                                  Function: 1-Axis Servo Drive
                                                  Manufacturer: Beckhoff Automation

                                                  The Beckhoff AX5112-0000-0200 is a high-performance single-axis digital servo drive from the AX5000 series. It supports 100–480 V AC, provides 12 A rated output current and 26 A peak current, and uses EtherCAT for high-speed, synchronized motion control. The specific -0200 version is hardware version 2.0 with firmware version 2.06 and OCT single-cable technology.

                                                  Technical Specifications

                                                  Parameter	Specification
                                                  Model	AX5112-0000-0200
                                                  Series	AX5000
                                                  Product Type	Digital Compact Servo Drive
                                                  Number of Axes	1
                                                  Rated Supply Voltage	3 × 100–480 V AC ±10%
                                                  Max. DC Link Voltage	875 V DC
                                                  Rated Output Current	12 A
                                                  Peak Output Current	26 A
                                                  Feedback	SinCos 1 Vpp, Resolver, EnDat 2.1, HIPERFACE, BiSS B, OCT
                                                  Communication	EtherCAT
                                                  Drive Profile	SERCOS profile / SoE
                                                  Hardware Version	2.0
                                                  Firmware Version	2.06
                                                  Motor Types	Synchronous, linear, torque, asynchronous, voice-coil
                                                  Operating Temperature	0–50°C
                                                  Width	92 mm
                                                  Height	317.7 mm
                                                  Depth	232 mm
                                                  Approx. Weight	5 kg
                                                  Approvals	CE, cULus

                                                  Specifications are based primarily on Beckhoff's official AX5112 documentation.

                                                  Advantages & Features

                                                  • High Dynamic Performance: Cascaded control loops support fast and highly dynamic positioning.
                                                  • EtherCAT Communication: High-speed, deterministic communication for synchronized motion control.
                                                  • Wide Voltage Range: Supports 100–480 V AC, suitable for various industrial power systems.
                                                  • 12 A Rated / 26 A Peak Current: Provides strong motor control capability.
                                                  • Multi-Feedback Support: Compatible with SinCos, resolver, EnDat, HIPERFACE, BiSS B and OCT feedback systems.
                                                  • OCT Single-Cable Technology: Supports simplified motor connection and reduced wiring.
                                                  • Flexible Motor Compatibility: Supports synchronous, linear, torque, asynchronous and voice-coil motors.
                                                  • Multi-Axis Expansion: AX-Bridge enables convenient connection of multiple AX5000 drives.
                                                  • Compact Cabinet Design: 92 mm wide housing helps save control cabinet space.
                                                  • Integrated Components: Power supply, EMC filter and DC-link capacitors are integrated into the drive.

                                                  Typical Applications

                                                  • Industrial automation
                                                  • CNC machinery
                                                  • Robotics
                                                  • Packaging machinery
                                                  • Semiconductor equipment
                                                  • Machine tools
                                                  • Pick-and-place systems
                                                  • High-speed positioning systems
                                                  • Conveyor and handling systems
                                                  • Multi-axis motion control
                                                  • Precision manufacturing equipment
