Beckhoff AM8121-0F10-0000 Servo Motor





Product Overview

The Beckhoff AM8121-0F10-0000 is a low-voltage synchronous servo motor from the Beckhoff AM8100 series, designed for high-dynamic motion control systems. It is typically used together with Beckhoff AX series servo drives or EtherCAT motion systems (TwinCAT).

This motor is a compact precision servo motor, suitable for applications requiring accurate positioning, smooth speed control, and fast response.

Key Specifications

• Brand: Beckhoff
• Model: AM8121-0F10-0000
• Series: AM8100 / AM8121 low-voltage servo motor series
• Type: AC synchronous servo motor
• Supply Voltage: < 50 V DC system (low-voltage drive architecture)
• Rated Speed: 3000 rpm
• Standstill Torque: approx. 0.5 Nm (depending winding)
• Peak Torque: up to ~2 Nm (variant dependent)
• Feedback System: OCT / absolute encoder (high-resolution, electronic nameplate)
• Flange Size: F2 (58 mm)
• Shaft: 9 k6, 20 mm shaft end
• Cooling: Natural convection
• Protection Class: IP54 / IP65 (variant dependent)

Advantages & Features

• High-precision servo positioning and speed control
• Compact design for tight machine integration
• High dynamic response suitable for fast motion systems
• Integrated absolute encoder for accurate positioning feedback
• Compatible with Beckhoff TwinCAT motion control system
• Stable performance in multi-axis synchronized systems

Applications

• Packaging machinery
• Robotics and pick-and-place systems
• CNC and precision automation equipment
• Printing and labeling machines
• Electronic assembly lines
• Industrial motion control systems

Precautions

• Must be used with compatible Beckhoff servo drive (AX series / EtherCAT system)
• Incorrect tuning may cause position error or vibration issues
• Encoder cable must be shielded and properly grounded
• Ensure correct motor parameters in TwinCAT (motor file / electronic nameplate)
• Do not operate without proper drive enable and safety circuit
• Installation should be performed by qualified motion control engineers
