YASKAWA SGDM-04AC-SD2B-1PC Servo Drive

Key Technical Specifications

• Sigma-II SGDM AC Servo Drive / SERVOPACK

• 200 V class, 3-phase 200–230 VAC input

• Approx. 3.4 A input current

• 0–230 VAC output

• 0–400 Hz output frequency

• Approx. 2.1 A output current

• 200 W rated applicable motor capacity

• Supports position, speed and torque control

• Closed-loop servo control with encoder feedback

• SD2B OEM-specific configuration

Advantages & Features

• High-precision servo positioning and speed control

• Closed-loop feedback for accurate motion control

• Compact Sigma-II SERVOPACK design

• Suitable for demanding industrial motion-control applications

• Designed for coordinated operation with compatible Yaskawa servo motors

Applications

• CNC machine tools

• Industrial automation

• Packaging machinery

• Precision positioning equipment

• Machine-tool feed systems

• Factory automation and motion-control systems

Precautions

• Verify compatibility with the exact Yaskawa Sigma-II servo motor before installation.

• The SD2B configuration may be OEM-specific; confirm connector wiring and parameter settings before replacement.

• Use the specified 200 V-class power supply.

• Do not connect or disconnect motor/encoder wiring while power is applied.

• Proper grounding and shielding are required for reliable servo operation.

• Confirm the exact machine/OEM configuration before replacing an existing unit.
