Yaskawa JVOP-160 Digital Operator Panel

Product Overview

The Yaskawa JVOP-160 is an LCD Digital Operator Panel (Keypad) designed for Yaskawa AC drives. It provides a human-machine interface for inverter operation, parameter setting, monitoring, fault diagnosis, and drive configuration. It is commonly used with Yaskawa G7, F7, P7, E7 and related drive series.

The operator allows users to locally control the drive, view operating status, modify parameters, perform auto-tuning, and troubleshoot inverter faults without using external software.

Main Specifications

• Manufacturer: Yaskawa
• Model: JVOP-160
• Product Type:
  • Digital Operator Panel
  • LCD Keypad
  • AC Drive Control Interface
• Display Type: LCD display
• Display Format: 5 lines × 16 characters
• Connection: Drive-mounted / Remote cable connection
• Compatible Series:
  • Yaskawa G7 Series
  • Yaskawa F7 Series
  • Yaskawa P7 Series
  • Yaskawa E7 Series

Technical Specifications

Display Functions

• LCD multi-line display
• Parameter number display
• Frequency reference display
• Output frequency monitoring
• Output current monitoring
• Voltage monitoring
• Fault and alarm indication
• Drive status monitoring

Control Functions

The JVOP-160 provides:

• RUN command
• STOP command
• Forward / Reverse operation
• Local / Remote mode switching
• Parameter editing
• Monitor selection
• Fault reset
• Auto-tuning operation

Keypad Functions

Main keys include:

• MENU — Select operation modes
• ESC — Return to previous menu
• DATA/ENTER — Confirm settings
• ▲ / ▼ — Parameter navigation and adjustment
• RUN — Start drive operation
• STOP — Stop drive operation
• RESET — Fault reset
• JOG — Jog operation
• FWD/REV — Direction control

Features & Advantages

• Original Yaskawa AC drive operator panel
• Clear LCD display for easy parameter viewing
• Simplifies inverter commissioning and maintenance
• Allows local operation without PLC connection
• Provides quick fault diagnosis
• Supports remote mounting with extension cable
• Reduces downtime during troubleshooting

Applications

Used in:

• Industrial automation systems
• Motor control cabinets
• Conveyor systems
• Pumps and fans
• Machine tools
• HVAC systems
• Production machinery

Typical applications:

• AC drive parameter setup
• Motor speed adjustment
• Drive status monitoring
• Fault troubleshooting
