- - - SIEMENS S55626-H517-C100 HVAC Controller Module

      Product Overview

      Brand: SIEMENS
      Model: S55626-H517-C100
      Type: HVAC Operator Interface / HMI Module
      Series: Climatix™
      Order Designation: POL871.72/STD
      Application: HVAC Control System Operation & Commissioning

      Note: The model S55626-H517-C100 is not an HVAC controller module itself. It is a Siemens Climatix HMI-TM operating unit (Human Machine Interface) used with Climatix HVAC controllers for display, operation, parameter setting, and commissioning.

      Technical Specifications

      General Data
      - Brand: SIEMENS
      - Model: S55626-H517-C100
      - Type: POL871.72/STD
      - Product Name: Climatix HMI-TM Operating Unit
      - Function: HVAC controller display and operator panel
      - Series: Climatix
      - Mounting Type: Panel mounting
      - Protection Rating: IP65 (front panel)
      - Application: HVAC equipment control and monitoring
      Display & User Interface

      Display
      - Display Type: Unicode LCD display
      - Display Lines: 8-line display
      - Backlight: Yes
      - Operation: Push-button interface
      Functions:
      - HVAC status display
      - Parameter adjustment
      - Alarm display
      - Service commissioning
      - Controller configuration
      Communication Interface

      Communication
      - Interface: Modbus communication
      - Connection: Ethernet cable / RJ45 connection
      - Cable Type: Cat-5 Ethernet cable
      - Connection Length: Approx. 1.5 m supplied cable
      Used with:
      - Siemens Climatix controllers
      - HVAC OEM controllers
      - Air handling unit controllers
      - Chiller and heat pump controllers
      Electrical Specifications

      Parameter Specification

      Supply Via controller interface

      Communication Modbus

      Connection RJ45

      Display 8-line Unicode LCD

      Backlight Supported

      Protection IP65 front mounting

      Mechanical Specifications
      - Mounting: Control panel installation
      - Housing: Panel mount design
      - Protection Class: IP65 front side
      - Weight: Approx. 0.366 kg
      - Installation Location: HVAC control cabinets / equipment panels
      Features & Advantages

      Easy HVAC Operation

      Provides a local user interface for HVAC equipment monitoring and adjustment.

      Commissioning Support

      Allows technicians to:
      - Configure parameters
      - Check alarms
      - Adjust operating modes
      - Perform maintenance operations
      Clear Display

      8-line backlit display improves readability during operation.

      Industrial Panel Design

      IP65 front protection makes it suitable for HVAC equipment installations.

      Siemens Climatix Compatibility

      Designed specifically for Siemens HVAC automation solutions.

      Typical Applications
      - Air Handling Units (AHU)
      - Chillers
      - Heat pumps
      - Ventilation systems
      - Building HVAC automation
      - OEM HVAC equipment
      - Energy management systems
      Compatible Equipment

      Commonly used with:
      - Siemens Climatix controllers
      - Siemens HVAC automation systems
      - HVAC OEM control panels
      - Building management systems (BMS)
      Installation Precautions
      - Confirm compatibility with the Siemens Climatix controller before installation.
      - Use the correct communication cable.
      - Ensure proper panel cutout dimensions.
      - Protect the rear side from moisture and dust.
      - Configure communication parameters before commissioning.
      - Disconnect power before wiring or replacement.
