    • SIEMENS 1XP8014-10 649989-03 Encoder Module

      Product Overview

      Brand: SIEMENS
      Model: 1XP8014-10
      ID Number: 649989-03
      Product Type: Absolute Encoder / Rotary Encoder
      Series: SIMOGEAR / Siemens Motor Encoder System
      Application: Motor Position Feedback / Motion Control

      The SIEMENS 1XP8014-10 (649989-03) is a multiturn absolute encoder used for Siemens motors and drive systems. It provides precise rotor position feedback through the EnDat 2.1 interface and is commonly used in Siemens geared motors, servo systems, and motion control applications.

      ---

      Technical Specifications

      General Data

      • Brand: SIEMENS
      • Model: 1XP8014-10
      • ID No.: 649989-03
      • Product Type: Absolute Rotary Encoder
      • Encoder Type: Multiturn Absolute Encoder
      • Interface: EnDat 2.1
      • Output Signal: Absolute position + incremental sine/cosine signals
      • Mounting: Motor shaft mounted
      • Protection Rating: IP66

      ---

      Encoder Performance

      Absolute Position Measurement

      • Communication Protocol: EnDat 2.1
      • Position Code: Dual code
      • Positions per Revolution: 8192 positions (13-bit)
      • Number of Differentiable Revolutions: 4096 revolutions
      • Measurement Type: Multiturn absolute position feedback



      ---

      Incremental Signal Output

      Sin/Cos Incremental Signals

      • Output Type: Sine/cosine signals A/B
      • Signal Level: Approx. 1 Vpp
      • Pulses per Revolution: 2048
      • Limit Frequency: ≥200 kHz
      • Signal Amplitude: 0.8…1.2 Vpp



      ---

      Electrical Specifications

      Parameter	Specification
      Supply Voltage	5 V ±5%
      Current Consumption	≤200 mA (without load)
      Interface	EnDat 2.1
      Incremental Output	1 Vpp Sin/Cos
      Resolution	13-bit absolute position
      Revolutions	4096 multiturn



      ---

      Mechanical Specifications

      • Encoder Type: Rotary shaft encoder
      • Connection: M23 flange connector, 17-pin
      • Mounting: Motor shaft installation
      • Operating Temperature: Approx. -10…100 °C
      • Housing Protection: IP66



      ---

      Communication Interface

      EnDat 2.1 Interface

      Functions:

      • Absolute position transmission
      • Motor position feedback
      • Speed feedback
      • Diagnostic data transmission
      • Parameter communication

      Compatible with:

      • Siemens SINAMICS drive systems
      • Siemens motion control systems
      • Siemens servo motors
      • Siemens geared motors



      ---

      Features & Advantages

      High-Precision Position Feedback

      Provides accurate rotor position information for closed-loop motor control.

      Multiturn Measurement

      Maintains position information over multiple revolutions without mechanical reset.

      EnDat Communication

      Supports fast digital communication with Siemens drive systems.

      Combined Absolute + Incremental Output

      Provides both:

      • Absolute position feedback
      • High-resolution speed feedback

      Industrial Protection

      IP66 enclosure design allows reliable operation in industrial environments.

      ---

      Typical Applications

      • Servo motor systems
      • CNC machines
      • Robotics equipment
      • Motion control systems
      • Packaging machinery
      • Automated production lines
      • Siemens SIMOGEAR geared motors
      • Industrial positioning systems

      ---

      Compatible Equipment

      Commonly used with:

      • Siemens SINAMICS drive systems
      • Siemens SIMODRIVE systems
      • Siemens servo motors
      • Siemens SIMOGEAR motors
      • Siemens motion controllers

      ---

      Installation Precautions

      • Confirm encoder compatibility with the motor model before installation.
      • Do not connect/disconnect encoder cables while powered.
      • Use correct EnDat-compatible cables.
      • Avoid mechanical shock during mounting.
      • Ensure encoder alignment with motor shaft.
      • Check shielding and grounding of encoder wiring.
      • Configure encoder parameters correctly in the drive system.

.The structure and details of the product：
