        • SIEMENS 7MF4033-1DA00-2AB7-Z-Y01-Y21-C12 Pressure Transmitter

          Product Overview

          Brand: SIEMENS
          Model: 7MF4033-1DA00-2AB7-Z-Y01-Y21-C12
          Product Type: Pressure Transmitter
          Series: SITRANS P DS III
          Measurement Type: Gauge Pressure Transmitter
          Communication: HART
          Output Signal: 4…20 mA
          Application: Industrial Process Pressure Measurement

          The SIEMENS 7MF4033-1DA00-2AB7-Z-Y01-Y21-C12 is a SITRANS P DS III HART pressure transmitter designed for accurate measurement of liquid, gas, and steam pressure in industrial process applications. It features a stainless-steel measuring cell, 4–20 mA output with HART communication, and customer-configured measuring range/display settings.

          ---

          Model Code Breakdown

          7MF4033-1DA00-2AB7-Z-Y01-Y21-C12

          Code	Description
          7MF4033	SITRANS P DS III pressure transmitter
          1	Silicone oil filling, normal cleaning
          D	Measuring span: 0.16…16 bar g
          A	Stainless steel diaphragm / wetted parts
          0	Process connection G½B according to EN 837-1
          0	Die-cast aluminum housing
          2	International version
          A	No explosion protection
          B	M20 × 1.5 cable gland
          7	Digital display visible
          Z	Additional customer options
          Y01	Customized measuring range
          Y21	Customized pressure display unit
          C12	Material traceability certificate



          ---

          Technical Specifications

          General Data

          • Brand: SIEMENS
          • Series: SITRANS P DS III
          • Model: 7MF4033-1DA00-2AB7-Z
          • Measurement Type: Gauge pressure
          • Sensor Type: Piezoresistive measuring cell
          • Communication: HART protocol
          • Output: 4…20 mA DC
          • Housing Material: Die-cast aluminum
          • Protection Rating: IP65
          • Mounting: Process installation



          ---

          Pressure Measurement Performance

          Measuring Range

          • Nominal Span: 0.16…16 bar g
          • Overload Limit: Approx. 32 bar
          • Pressure Type: Gauge pressure

          The Y01 option allows factory configuration of the desired measuring range, for example:

          • 0…10 bar
          • 0…16 bar
          • Other pressure ranges within transmitter limits



          ---

          Output & Communication

          Analog Output

          • Signal: 4…20 mA
          • Communication: HART 5.x
          • Power Supply: Approx. 10.5…45 V DC

          HART Functions

          Supports:

          • Parameter configuration
          • Device diagnostics
          • Calibration adjustment
          • Process value monitoring



          ---

          Display Function

          Digital Indicator

          The transmitter includes:

          • Integrated LCD display
          • Pressure value indication
          • Configurable engineering units

          Supported units include:

          • bar
          • mbar
          • psi
          • kPa
          • MPa
          • inH₂O
          • mmHg

          The Y21 option specifies the required pressure display unit.

          ---

          Process Connection

          Connection Type

          • Thread: G½B
          • Standard: EN 837-1
          • Wetted Material: Stainless steel

          Suitable for:

          • Liquids
          • Gases
          • Steam applications



          ---

          Electrical Specifications

          Parameter	Specification
          Supply Voltage	10.5…45 V DC
          Output Signal	4…20 mA
          Communication	HART
          Load Resistance	230…1100 Ω (HART communication)
          Electrical Connection	M20 × 1.5 cable gland



          ---

          Accuracy & Reliability

          Features:

          • High measurement stability
          • Temperature compensation
          • Digital sensor processing
          • Self-diagnostic functions
          • Long-term industrial operation capability

          Suitable for demanding process environments.

          ---

          Features & Advantages

          High Accuracy Pressure Measurement

          Provides reliable pressure monitoring for industrial processes.

          HART Communication Capability

          Allows remote configuration and diagnostics.

          Robust Industrial Design

          Stainless steel measuring cell and aluminum housing provide durability.

          Flexible Configuration

          Supports customized:

          • Pressure range
          • Display units
          • Calibration options

          Wide Industrial Compatibility

          Integrates easily with:

          • PLC systems
          • DCS systems
          • Process control systems

          ---

          Typical Applications

          • Chemical processing
          • Oil & gas systems
          • Water treatment plants
          • Power generation
          • Steam systems
          • Hydraulic systems
          • Process automation
          • Industrial machinery

          ---

          Compatible Equipment

          Commonly used with:

          • Siemens PCS 7 DCS
          • Siemens SIMATIC systems
          • HART communicators
          • Process control systems
          • Industrial PLC analog input modules

          ---

          Installation Precautions

          • Verify pressure range before installation.
          • Ensure process connection matches pipeline specifications.
          • Avoid exceeding maximum pressure limit.
          • Use shielded signal cables for 4–20 mA wiring.
          • Confirm correct power supply polarity.
          • Perform zero adjustment after installation if required.
          • Avoid mechanical shock during mounting.

.The structure and details of the product：
