          • SIEMENS 6ES7322-1HF10-0AA0 SIMATIC S7 Digital Output Module

            Product Overview

            Brand: SIEMENS
            Model: 6ES7322-1HF10-0AA0
            Product Type: Digital Output Module
            Series: SIMATIC S7-300 / SM 322
            Application: PLC Digital Output Control

            The SIEMENS 6ES7322-1HF10-0AA0 is an SM 322 digital output module for the SIMATIC S7-300 PLC system. It provides 8 relay digital outputs with electrical isolation and supports switching loads up to 5 A at 24 V DC or 230 V AC. It is commonly used for controlling contactors, valves, motors, lamps, and other industrial actuators.

            ---

            Technical Specifications

            General Data

            • Brand: SIEMENS
            • Model: 6ES7322-1HF10-0AA0
            • Series: SIMATIC S7-300
            • Module Type: SM 322 Digital Output Module
            • Output Type: Relay Output
            • Number of Outputs: 8 Digital Outputs
            • Isolation: Optically isolated
            • Front Connector: 40-pin
            • Mounting: S7-300 rack mounting
            • Protection Class: IP20

            ---

            Digital Output Specifications

            Relay Outputs

            • Number of Channels: 8
            • Output Type: Relay contacts
            • Rated Output Current: 5 A
            • Minimum Load Current: 5 mA
            • Switching Voltage:
              • Up to 24 V DC
              • Up to 230 V AC

            Output applications:

            • Contactors
            • Solenoid valves
            • Motors
            • Signal lamps
            • Heating elements
            • Industrial actuators



            ---

            Electrical Specifications

            Parameter	Specification
            Load Voltage DC	24 V DC
            Load Voltage AC	230 V AC
            Output Current	5 A/channel
            Backplane Bus Current	Max. 40 mA
            Supply Current L+	Max. 125 mA
            Power Dissipation	Approx. 3.2 W
            Short Circuit Protection	External protection required



            ---

            Switching Performance

            Switching Frequency

            • Resistive load: Max. 2 Hz
            • Inductive load: Max. 0.5 Hz
            • Lamp load: Max. 2 Hz
            • Mechanical switching: Max. 10 Hz

            Switching Capacity

            Typical applications:

            • 230 V AC loads
            • 24 V DC loads
            • Industrial relay switching circuits



            ---

            Diagnostic & Status Functions

            The module provides:

            • Channel status LEDs
            • Output status indication
            • Isolation between outputs and PLC bus

            Note:

            • No integrated diagnostic interrupt function
            • No short-circuit protection inside module



            ---

            Communication Interface

            SIMATIC S7 Backplane Bus

            Compatible with:

            • Siemens S7-300 CPUs
            • ET 200M distributed I/O systems

            Functions:

            • PLC output data exchange
            • Module identification
            • Process control signal output



            ---

            Mechanical Specifications

            • Mounting: DIN rail / S7-300 rack
            • Dimensions: Approx. 40 × 125 × 120 mm
            • Weight: Approx. 320 g
            • Installation: Control cabinet mounting
            • Protection: IP20



            ---

            Features & Advantages

            Relay Output Design

            Relay contacts allow switching of both AC and DC loads.

            Electrical Isolation

            Provides separation between PLC control electronics and field devices.

            High Load Capability

            Supports up to 5 A output current per channel.

            Flexible Industrial Applications

            Suitable for various actuator control tasks.

            Siemens SIMATIC Compatibility

            Integrates easily into existing S7-300 automation systems.

            ---

            Typical Applications

            • Factory automation systems
            • Machine control cabinets
            • Motor starter control
            • Valve and actuator control
            • Conveyor systems
            • HVAC automation
            • Process control systems
            • Industrial equipment upgrades

            ---

            Compatible Equipment

            Commonly used with:

            • Siemens SIMATIC S7-300 CPUs
            • Siemens ET 200M systems
            • Siemens STEP 7 engineering software
            • Industrial contactors
            • Solenoid valves
            • Motor control equipment

            ---

            Installation Precautions

            • Confirm output load voltage before wiring.
            • Use external protection devices for short-circuit protection.
            • Do not exceed 5 A per output channel.
            • Check relay contact ratings for inductive loads.
            • Install in a suitable control cabinet environment.
            • Disconnect power before module replacement.
            • Configure hardware correctly in STEP 7 software.

.The structure and details of the product：
