- - - - SIEMENS 6EP1336-3BA10 Power Supply Module

        Product Overview

        Brand: SIEMENS
        Model: 6EP1336-3BA10
        Product Type: Stabilized DC Power Supply Module
        Series: SITOP PSU8200
        Application: Industrial Automation Power Supply

        The SIEMENS 6EP1336-3BA10 is a SITOP PSU8200 stabilized power supply module designed to provide a reliable 24 V DC output for industrial automation systems. It delivers 20 A output current (480 W) and supports a wide input range of 120–230 V AC / 110–220 V DC, making it suitable for PLC systems, control cabinets, sensors, actuators, and industrial communication equipment.

        Technical Specifications

        General Data

        Brand: SIEMENS

        Model: 6EP1336-3BA10

        Series: SITOP PSU8200

        Type: AC/DC Switching Power Supply

        Output Voltage: 24 V DC

        Output Current: 20 A

        Output Power: 480 W

        Mounting: DIN rail mounting

        Protection Rating: IP20

        Design: Stabilized industrial power supply

        Electrical Specifications

        Input Specifications

        Input Voltage (AC):

        120…230 V AC

        Wide range: 85…275 V AC

        Input Voltage (DC):

        110…220 V DC

        Input range: 88…350 V DC

        Frequency: 50/60 Hz

        Input Type: 1-phase / 2-phase AC or DC

        Input current:

        Approx. 4.6 A at 120 V AC

        Approx. 2.5 A at 230 V AC

        Output Specifications

        DC Output

        Rated Output Voltage: 24 V DC

        Output Current: 20 A

        Output Power: 480 W

        Adjustable Output Voltage: Yes

        Output Voltage Range: Approx. 24…28.8 V DC

        Applications:

        PLC power supply

        Remote I/O modules

        HMI systems

        Sensors and actuators

        Industrial Ethernet devices

        Protection Functions

        The module includes:

        Short-circuit protection

        Overload protection

        Overvoltage protection

        Overtemperature protection

        Current limiting function

        Protection features ensure safe operation under abnormal conditions.

        Performance Characteristics

        Power Failure Buffering

        Buffer time: Minimum approx. 20 ms at rated load

        Condition: Input voltage 230 V AC

        Efficiency

        Approx. 93% (typical)

        Status Indication

        Green LED:

        24 V output OK

        Mechanical Specifications

        Parameter Specification

        Mounting DIN rail TH35

        Dimensions Approx. 90 × 125 × 125 mm

        Weight Approx. 1.06 kg

        Protection Class IP20

        Connection Screw terminal

        Communication & Monitoring

        The power supply provides:

        24 V DC output terminals

        Status monitoring interface

        LED operation indication

        Optional SITOP modules can be used for:

        Diagnostics

        Buffering

        Selectivity monitoring

        Redundancy solutions

        Features & Advantages

        High Output Capacity

        Provides up to 20 A / 480 W, suitable for large automation cabinets.

        Wide Input Range

        Supports different international power networks.

        Stable 24 V DC Supply

        Ensures reliable operation of:

        PLC controllers

        Industrial computers

        Field devices

        Industrial Reliability

        Designed for continuous operation in harsh automation environments.

        Compact DIN Rail Design

        Saves control cabinet space and simplifies installation.

        Typical Applications

        Industrial control cabinets

        Siemens SIMATIC PLC systems

        Factory automation equipment

        Machine tools

        Robotics systems

        Production lines

        Process control systems

        Industrial communication networks

        Compatible Equipment

        Commonly used with:

        Siemens SIMATIC S7 PLC

        Siemens ET 200 distributed I/O

        Siemens HMI panels

        Industrial Ethernet switches

        Sensors and actuators

        Automation controllers

        Installation Precautions

        Verify input voltage before wiring.

        Ensure correct 24 V DC polarity.

        Do not exceed 20 A output current.

        Provide sufficient ventilation inside the cabinet.

        Install appropriate circuit protection on the input side.

        Avoid operation outside specified temperature limits.

        Disconnect power before maintenance.
