SIEMENS DXR2.E18-101A Room Automation Controller

Item NO.:
DXR2.E18-101A
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

- - - - SIEMENS DXR2.E18-101A Room Automation Controller

        Product Overview

        Brand: SIEMENS
        Model: DXR2.E18-101A
        Product Type: Room Automation Controller / Compact Room Automation Station
        Series: Desigo Room Automation (DXR2 Series)
        Application: HVAC, lighting, shading and building automation control

        The SIEMENS DXR2.E18-101A is a compact room automation station from the Desigo Room Automation platform. It integrates HVAC, lighting, and shading control functions into a single BACnet/IP controller. It is designed for intelligent building automation applications such as fan coil units, radiant ceilings, radiators, lighting control and blinds/shading systems.

        Technical Specifications

        General Data

        Brand: SIEMENS

        Model: DXR2.E18-101A

        Stock Number: S55376-C107

        Series: Desigo Room Automation DXR2

        Type: Compact Room Automation Station

        Communication: BACnet/IP

        Mounting: DIN rail mounting / room installation

        Protection Class: IP20

        Supply Voltage: AC 24 V

        Frequency: 50/60 Hz

        Input & Output Configuration

        Digital Inputs

        Number of Digital Inputs: 2 DI

        Used for:

        Window contacts

        Presence detectors

        External switches

        Alarm signals

        Universal Inputs

        Number of Universal Inputs: 4 UI

        Supports:

        Temperature sensors

        Humidity sensors

        CO₂ sensors

        Analog signals

        Binary signals

        Analog Outputs

        Number of Analog Outputs: 4 AO

        Output Signal: 0…10 VDC

        Maximum Output Current: 1 mA

        Used for:

        Valve actuators

        Damper actuators

        Variable speed controllers

        Triac Outputs

        Number of Triac Outputs: 8

        Switching Voltage: AC 24 V

        Maximum Switching Current: 250 mA

        Used for:

        Thermal valve actuators

        Fan coil valves

        Heating/cooling control devices

        Communication Interfaces

        BACnet/IP Communication

        Supports:

        BACnet/IP building automation network

        Integration with Desigo building management systems

        Central monitoring and control

        KNX PL-Link Interface

        Supports:

        Siemens KNX PL-Link sensors

        Room operator units

        Field devices with bus power supply

        Additional Interfaces

        2-port Ethernet switch

        USB service interface for commissioning tools

        Supported Applications

        The DXR2.E18-101A is preconfigured for applications including:

        Fan coil units (FCU)

        Dual duct VAV systems

        Radiant ceiling systems

        Radiator control

        Lighting control

        Blind/shading control

        Electrical Specifications

        Operating Voltage: AC 24 V (-15%/+20%)

        Frequency: 50/60 Hz

        Power Consumption: Approx. 78 VA

        Triac Output Load: 250 mA/channel

        Analog Output: 0…10 VDC

        Mechanical Specifications

        Mounting: DIN housing

        Dimensions (W × H × D):

        Approx. 180 × 105 × 60 mm

        Installation Location:

        Control cabinet

        Building automation panels

        Room automation boxes

        Features & Advantages

        Integrated Room Control

        Combines HVAC, lighting and shading control in one compact controller.

        BACnet/IP Connectivity

        Provides easy connection to building management systems.

        Flexible I/O Design

        Supports multiple sensors and actuators without additional modules.

        KNX Integration

        Allows connection of Siemens room operating units and KNX devices.

        Energy Efficiency

        Supports intelligent room control strategies to optimize comfort and energy consumption.

        Typical Applications

        Office buildings

        Hotels

        Hospitals

        Commercial buildings

        Smart buildings

        Conference rooms

        Industrial office areas

        HVAC automation systems

        Compatible Equipment

        Commonly used with:

        SIEMENS Desigo building automation systems

        BACnet/IP networks

        KNX PL-Link room sensors

        HVAC terminal units

        Siemens room operator units

        Installation Precautions

        Verify AC 24 V power supply before installation.

        Confirm BACnet/IP network settings.

        Ensure correct KNX PL-Link wiring.

        Check actuator voltage compatibility.

        Configure application parameters before commissioning.

        Use proper grounding and shielded communication wiring.

        Ensure sufficient cabinet ventilation.
