SIEMENS VIPA 331-1KF01 S7 Analog Input Module

Item NO.:
VIPA 331-1KF01
Market Price:
$500
Product Origin:
Germany
Color:
NEW
Product weight:
0.01KG
Lead Time:
In stock

- - - - SIEMENS VIPA 331-1KF01 S7 Analog Input Module

        Product Overview

        Brand: VIPA (compatible with Siemens S7-300)
        Model: 331-1KF01
        Product Type: Analog Input Module
        Series: VIPA System 300V / S7 Compatible I/O
        Equivalent Siemens Module: 6ES7 331-1KF01-0AB0
        Application: Analog signal acquisition for PLC automation systems

        The VIPA 331-1KF01 is an SM331-compatible analog input module designed for Siemens S7-300 compatible automation systems. It converts analog field signals such as voltage, current, resistance, RTD and thermocouple signals into digital values for PLC processing.

        Technical Specifications

        General Data

        Brand: VIPA

        Model: 331-1KF01

        Series: System 300V

        Type: Analog Input Module (AI)

        Compatible System: Siemens S7-300

        Equivalent Siemens Part: 6ES7 331-1KF01-0AB0

        Module Type: SM331 Analog Input

        Mounting: S7-300 rail mounting

        Front Connector: 40-pin connector

        Analog Input Specifications

        Input Channels

        Number of Analog Inputs: 8 channels

        Resolution: 13-bit (12 bit + sign)

        Isolation: Isolated from backplane bus

        Conversion Principle: Sigma-delta conversion

        Input Data: 8 words

        Supported Input Signals

        Voltage Inputs

        Supports:

        ±50 mV

        ±500 mV

        ±1 V

        ±5 V

        ±10 V

        0…10 V

        1…5 V

        Current Inputs

        Supports:

        ±20 mA

        0…20 mA

        4…20 mA

        Resistance / Temperature Inputs

        Supports:

        Resistance measurement:

        0…600 Ω

        0…6000 Ω

        Resistance temperature sensors:

        Pt100

        Ni100

        Ni1000

        LG-Ni1000

        Thermocouple measurement (depending on configuration)

        Electrical Specifications

        Backplane Bus Current Consumption: Approx. 200 mA

        Power Dissipation: Approx. 1 W

        Isolation Test Voltage: 500 VDC

        Sensor Supply Current:

        Approx. 0.83 mA for resistance thermometer measurement

        Approx. 0.25 mA for resistance measurement

        Measurement Performance

        Integration Time: Approx. 60 ms (default)

        Conversion Time: Approx. 61 ms/channel

        Noise Suppression: 50/60 Hz interference suppression

        Linearity Error: Approx. 0.02%

        Repeatability: Approx. 0.05%

        Communication & Compatibility

        Compatible with:

        VIPA System 300V PLC

        Siemens SIMATIC S7-300 CPU systems

        Siemens STEP 7 hardware configuration environment

        The module is pin and function compatible with Siemens SM331 analog input modules.

        Features & Advantages

        Multi-Signal Compatibility

        Supports voltage, current, resistance and temperature sensor inputs.

        Siemens S7 Compatibility

        Can be configured like Siemens S7-300 SM331 modules.

        High Accuracy Signal Conversion

        13-bit resolution provides reliable analog measurement.

        Industrial Isolation Design

        Provides protection between field signals and PLC backplane.

        Flexible Automation Integration

        Suitable for upgrading or replacing older S7-300 analog input systems.

        Typical Applications

        Process control systems

        Temperature monitoring

        Pressure measurement

        Flow control systems

        Industrial weighing systems

        Machine automation

        Factory production lines

        Compatible Equipment

        Commonly used with:

        VIPA System 300V PLC

        Siemens SIMATIC S7-300 PLC

        Siemens STEP 7 engineering software

        Industrial sensors and transmitters

        Installation Precautions

        Confirm PLC compatibility before installation.

        Use correct 40-pin front connector.

        Configure input type before connecting sensors.

        Do not connect voltage signals when configured for current input.

        Verify wiring polarity and shielding.

        Disconnect power before replacing the module.

        Perform hardware configuration in STEP 7 after installation.
