PROSOFT AN-X4-AB-DHRIO EtherNet/IP to Data Highway Plus Gateway

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • • • • • • •

                      • PROSOFT AN-X4-AB-DHRIO EtherNet/IP to Data Highway Plus Gateway

                        The ProSoft AN-X4-AB-DHRIO is an EtherNet/IP to Data Highway Plus (DH+) Gateway designed to connect modern Ethernet-based PLCs, HMIs and engineering stations with legacy Allen-Bradley PLC-5 and SLC systems. It can also operate in Remote I/O and Bridge modes for migration and integration applications.

                        Key Technical Specifications

                        Parameter	Specification
                        Brand	ProSoft Technology
                        Model	AN-X4-AB-DHRIO
                        Product Type	EtherNet/IP to DH+ Gateway
                        Ethernet Port	1 × RJ45, 10/100 Mbps
                        DH+ Baud Rates	57.6 / 115.2 / 230.4 kbps
                        Power Supply	12–24 VDC
                        Typical Consumption	240 mA @ 12 VDC / 120 mA @ 24 VDC
                        Max. Power Dissipation	2.9 W
                        Operating Temperature	0 to 50°C
                        Storage Temperature	-40 to 85°C
                        Humidity	5–95%, non-condensing
                        Dimensions	107 × 98 × 34 mm
                        Mounting	DIN rail / desktop
                        Configuration	Built-in web server
                        Network	EtherNet/IP / Data Highway Plus

                        The gateway supports access to legacy DH+ processors from EtherNet/IP networks, including downloading to PLC-5 or SLC controllers through RSLinx.

                        Advantages & Features

                        • Bridges EtherNet/IP and legacy DH+ networks
                        • Helps modernize legacy Allen-Bradley control systems
                        • Supports PLC-5 and SLC communication
                        • Multiple DH+ baud rates supported
                        • Built-in web interface for configuration and diagnostics
                        • DIN-rail mountable
                        • Supports migration without immediately replacing legacy PLC hardware
                        • Can operate in multiple integration modes

                        Typical Applications

                        • Allen-Bradley PLC-5 modernization
                        • SLC 500 system migration
                        • Legacy DH+ network integration
                        • ControlLogix / EtherNet/IP to DH+ communication
                        • HMI and SCADA connectivity
                        • Industrial automation network upgrades
                        • Factory and process-control systems

                        Important Precautions

                        • Confirm that the existing legacy network uses Data Highway Plus (DH+) rather than Remote I/O or another protocol.
                        • Verify the DH+ node address and baud rate before commissioning.
                        • Configure the Ethernet network and IP address correctly.
                        • Use the appropriate Phoenix connectors and wiring.
                        • Confirm firmware compatibility when replacing an existing AN-X or AN-X2 gateway.
                        • This device is a communication gateway, not an I/O module.
