LENZE I5DAE255F10010000S Frequency Inverter





Product Overview

The LENZE I5DAE255F10010000S is a 3-phase vector frequency inverter (VFD) from the Lenze i500 series, designed for speed control of AC induction motors in industrial automation systems.

It converts fixed-frequency AC power into a variable frequency and voltage output, allowing precise motor speed regulation.

Key Specifications

• Brand: Lenze
• Model: I5DAE255F10010000S
• Series: i500 / i550 vector inverter family
• Type: Frequency Inverter (VFD / Variable Speed Drive)
• Rated Power: 5.5 kW (heavy duty)
• Input Voltage: 3-phase 380–480 VAC
• Output Current: approx. 13 A (heavy duty at 400V)
• Output Frequency: up to ~599 Hz
• Control Mode: Vector control / V/f control
• Control Inputs: Analog (0–10V, 4–20mA) + digital I/O
• Mounting: Cabinet / panel mounting (IP20)
• Programming: Keypad / PC software

Advantages & Features

• High precision motor speed and torque control
• Supports vector control for stable low-speed operation
• Built-in protection: overvoltage, overload, overtemperature
• Flexible analog + digital control interfaces
• Compact industrial design for cabinet installation
• Suitable for continuous industrial duty applications

Applications

• Conveyor systems
• Pumps and fans
• Packaging machinery
• Textile and printing machines
• Material handling systems
• Industrial automation production lines

Precautions

• Must be installed in a proper ventilated control cabinet
• Incorrect parameter settings may damage motor or load
• Ensure correct motor wiring (U/V/W + grounding)
• Use shielded cable for motor output to reduce EMI
• Do not exceed rated motor power (5.5 kW typical load limit)
• Parameter tuning required for stable vector control operation
