Lenze ESV402N06TXB AC Drive

Product Overview

The Lenze ESV402N06TXB is a Lenze AC Tech SMVector Series Variable Frequency Drive (VFD), designed for controlling the speed, torque, and operation of AC induction motors. It provides reliable motor control for industrial automation applications such as conveyors, pumps, fans, and machinery.

This model is a 5 HP (4.0 kW) frequency inverter with 480–600 VAC three-phase input, suitable for industrial motor speed regulation and energy-saving applications.

Main Specifications

• Manufacturer: Lenze / AC Tech
• Model: ESV402N06TXB
• Series: SMVector
• Product Type:
  • AC Drive
  • Variable Frequency Drive (VFD)
  • Frequency Inverter
• Rated Power: 4.0 kW / 5 HP
• Input Voltage: 480–600 VAC
• Input Phase: 3 Phase
• Output Voltage: 3 Phase AC
• Output Current: 6.1 A
• Frequency Range: 0–500 Hz
• Enclosure Rating: NEMA 1 / IP31
• Cooling Method: Fan cooled

Technical Functions

The ESV402N06TXB provides:

• AC motor speed control
• Variable frequency operation
• Acceleration and deceleration control
• Torque regulation
• Motor protection functions

Working principle:

AC Power Input → VFD Converter → Variable Frequency Output → AC Motor Speed Control

Control Features

• Sensorless vector control
• V/Hz control mode
• Adjustable speed control
• Auto-tuning capability
• Digital and analog input control
• Built-in keypad operation

Interface Specifications

Features & Advantages

• Original Lenze SMVector series drive
• Compact industrial design
• Supports precise motor speed adjustment
• Improves energy efficiency
• Reliable overload protection
• Easy parameter setup and maintenance
• Suitable for retrofit and replacement applications

Applications

Used in:

• Factory automation equipment
• Conveyor systems
• Pump and fan systems
• Packaging machinery
• Material handling equipment
• Industrial production lines

Typical applications:

• Motor speed regulation
• Variable speed control
• Process automation
• Energy-saving motor operation
