HONEYWELL RA890G1245 Burner Control Relay

Product Description

Honeywell RA890G1245 is a Protectorelay™ Primary Burner Control Relay designed for industrial and commercial gas, oil, or combination gas-oil burner systems. It provides flame safeguard protection by continuously monitoring the burner flame and safely shutting down the fuel supply if a flame failure is detected.

The RA890G series is intended for use with compatible Honeywell flame amplifiers, UV flame detectors, flame rods, or photocells, depending on the system configuration. It is widely used in boilers, furnaces, ovens, kilns, and other combustion equipment requiring reliable flame supervision.

Technical Parameters

• Brand: Honeywell
• Model: RA890G1245
• Product Type: Protectorelay™ Primary Burner Control Relay
• Application: Industrial and commercial burner management
• Fuel Types:
  • Natural gas
  • Fuel oil
  • Combination gas/oil
• Supply Voltage: 220 VAC
• Frequency: 50/60 Hz
• Safety Switch Timing: 15 seconds
• Flame Failure Response Time (FFRT): 0.8 second
• Alarm Contacts: SPDT relay
• Flame Detection: Compatible with UV detectors, flame rod, or photocell (depending on amplifier configuration)
• Mounting: Q270 wiring subbase
• Control Type: Solid-state flame safeguard relay
• Approvals: UL, CSA, FM, AGA (model dependent)

Advantages & Features

• Original Honeywell Protectorelay™ burner control
• Solid-state flame safeguard protection
• Fast 0.8-second flame failure response
• Reliable burner shutdown during unsafe flame conditions
• SPDT alarm relay output
• Compatible with multiple Honeywell flame detection methods
• Rugged industrial design for continuous operation
• Suitable for gas, oil, and dual-fuel burner systems
• Easy replacement using the Honeywell Q270 mounting base

Applications

• Industrial boilers
• Commercial boilers
• Industrial furnaces
• Kilns
• Dryers
• Process heaters
• Combustion systems
• Burner Management Systems (BMS)

Notes

• RA890G1245 is a burner flame safeguard primary control relay, not a general-purpose industrial relay.
• Verify the supply voltage (220 VAC), flame amplifier, flame detector type, and mounting base compatibility before installation.
• Functional flame safety testing should always be performed after installation or replacement.
• Honeywell recommends migration to the 7800 Series for many legacy RA890G applications where appropriate.
