HONEYWELL ML7420A6025 Electric Valve Actuator

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • • • • • •

            • Product Overview

              The Honeywell ML7420A6025 is an electric linear valve actuator designed for modulating control of compatible HVAC and heating-system valves. It uses a 2–10 V DC control signal to position the valve, helping regulate water flow and maintain temperature in heating, ventilation, and air-conditioning systems.



              Honeywell+1



              Technical Specifications

              Parameter	Specification
              Brand	Honeywell
              Model	ML7420A6025
              Product Type	Electric Linear Valve Actuator
              Actuator Type	Modulating
              Supply Voltage	24 V AC ±15%
              Frequency	50/60 Hz
              Power Consumption	5 VA
              Control Signal	2–10 V DC
              Stroke Length	20 mm
              Closing Force	At least 600 N
              Travel Time	Approx. 60 seconds at 50 Hz
              Ambient Operating Temperature	-10°C to +50°C
              Ambient Storage Temperature	-40°C to +70°C
              Protection Rating	IP52 in the referenced datasheet
              Weight	Approx. 1.3 kg
              Compatible Valve Series	V5011, V5013, V5016A, V5025, V5049, V5050, V5328, V5329



              prod-edam.honeywell.com+2

              Key Features

              • Precise modulating control using a 2–10 V DC input.

              • 20 mm linear actuator stroke.

              • 600 N closing force.

              • Selectable direct or reverse action.

              • Force-limiting end stops.

              • Low power consumption and maintenance-free design.



                Honeywell+1



              Typical Applications

              • HVAC water control systems

              • Heating and district heating systems

              • Chilled-water control

              • Building automation

              • Industrial temperature regulation

              Installation Notes

              • Verify compatibility with the installed valve body.

              • Confirm the 24 V AC supply and 2–10 V DC control signal.

              • Check the required stroke and closing force.

              • Installation and commissioning should be performed by qualified technicians.
