HONEYWELL HAVDTXX-EU Control Module

Product Description
Honeywell HAVDTXX-EU is a Duct Air Velocity Transmitter used in Honeywell building automation and HVAC control systems. It is designed to measure air velocity and temperature inside air ducts and provide output signals to electronic controllers for ventilation and air-conditioning regulation.

Although often listed as a "Control Module", HAVDTXX-EU is actually an airflow measurement transmitter/sensor, not a PLC controller or standalone control CPU. It is mainly used for HVAC environmental monitoring and automatic air handling control applications.

Technical Parameters

• Brand: Honeywell
• Model: HAVDTXX-EU
• Product Type: Duct Air Velocity Transmitter
• Application: HVAC / Building Automation System
• Measurement:
  • Air velocity
  • Air temperature
• Velocity Measuring Range:
  • 0–2 m/s
  • 0–10 m/s
  • 0–20 m/s
• Output Signal:
  • 0–10 V
  • 4–20 mA
• Power Supply: 24 VAC / 24 VDC ±10%
• Current Consumption: Approx. 35–90 mA depending on relay use
• Temperature Measurement Output: 0–10 V or 4–20 mA
• Air Velocity Accuracy:
  • ±0.2 m/s + 5% reading (0–2 m/s range)
  • ±0.5 m/s + 5% reading (0–10 m/s range)
  • ±1.0 m/s + 5% reading (0–20 m/s range)
• Probe Length: 210 mm
• Insertion Length: Adjustable 50–180 mm
• Protection Rating: IP54
• Operating Temperature: 0–50°C
• Humidity: 0–95% RH non-condensing
• Communication Interface: Analog signal output
• Country of Origin: Finland

Advantages & Features

• Original Honeywell HVAC sensing component
• Accurate duct airflow velocity measurement
• Integrated air temperature measurement
• Multiple selectable velocity ranges
• Supports 0–10 V and 4–20 mA industrial signals
• Compatible with Honeywell building management controllers
• Compact duct mounting design
• Suitable for continuous HVAC monitoring applications

Applications

• HVAC air handling units (AHU)
• Ventilation control systems
• Building Management Systems (BMS)
• Clean room airflow monitoring
• Commercial building climate control
• Industrial ventilation systems
• Energy management systems

Notes

• HAVDTXX-EU is an airflow transmitter, not a controller module.
• Confirm input signal requirements of the connected controller before installation.
• Ensure correct probe insertion depth and airflow direction.
• Avoid installation near turbulence sources such as bends, fans, or dampers to maintain measurement accuracy.
