HONEYWELL FC-SDO-0824 Safety Digital Output Module
Item NO.:
FC-SDO-0824Payment:
T/TPrice:
$1280Product Origin:
USAColor:
NEWProduct weight:
0.35kgLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
|
Parameter |
Specification |
|---|---|
|
Brand |
HONEYWELL |
|
Model |
FC-SDO-0824 |
|
Product Type |
Safety Digital Output Module |
|
System |
Honeywell Safety Manager |
|
Number of Channels |
8 |
|
Output Voltage |
24 V DC |
|
Output Type |
Solid-state sourcing |
|
Maximum Output Current |
550 mA per channel, subject to derating |
|
Maximum Lamp Load |
120 mA (2.9 W) |
|
Maximum Load Capacitance |
1 µF |
|
Voltage Drop |
Less than 2.0 V at 500 mA |
|
Off-State Current |
Less than 0.1 mA |
|
Power Requirements |
5 V DC and 24 V DC internal/external supplies |
|
Protection |
Short-circuit protection |
|
Diagnostics |
Output testing and fault monitoring |
|
Construction |
Conformal-coated version |
|
Approvals |
CE, TÜV, UL, CSA, FM |
Specifications are based on Honeywell's Safety Manager hardware reference. Maximum output current depends on operating temperature and load conditions.
Safety-Critical Control: Designed for safety-related output applications.
Eight Output Channels: Controls multiple field devices from one module.
Short-Circuit Protection: Helps protect output circuits against electrical faults.
Built-In Diagnostics: Supports output testing and fault detection.
Conformal Coating: Provides additional protection for electronic components.
Reliable Switching: Suitable for compatible safety shutdown and interlock circuits.
Emergency shutdown (ESD) systems
Fire and gas safety systems
Safety solenoid valves
Industrial process control
Oil and gas facilities
Chemical and petrochemical plants
Power generation systems
Verify compatibility with the Honeywell Safety Manager chassis and approved field termination assembly.
Confirm the 24 V DC field supply polarity and current requirements.
Ensure each channel's load remains within current, capacitance, and temperature limits.
Follow the manufacturer's wiring and safety configuration procedures.
Test output operation and de-energized safe states during commissioning.
Installation and functional safety testing must be performed by qualified personnel.
