Honeywell 05701-A-0329 Triple DPCO Relay Card

Honeywell 05701-A-0329 Triple DPCO Relay Card

Honeywell 05701-A-0329 Triple DPCO Relay Card

  • Item NO.:

    05701-A-0329
  • Payment:

    T/T
  • Product Origin:

    USA
  • Color:

    NEW
  • Product weight:

    0.22KG
  • Lead Time:

    In stock

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.



Honeywell 05701-A-0329 Triple DPCO Relay Card

Product Overview

The 05701-A-0329 is a triple DPCO (Double-Pole Changeover) relay card designed for industrial control systems, particularly in safety-critical applications such as gas detection and process automation. It is part of Honeywell's 5700 series control systems, providing reliable switching capabilities for alarm and control circuits .


Key Features

✅ Triple DPCO Relay Configuration

  • 3 independent relays, each with double-pole changeover (DPCO) contacts for flexible circuit control .

  • Contact Rating: Typically 5A @ 250V AC/30V DC, suitable for industrial loads .

✅ High Reliability & Safety

  • Fail-safe design: Relays default to a safe state during power loss .

  • Isolation: 2500V isolation between relay coils and contacts for noise immunity .

✅ Industrial Durability

  • Operating Temperature: -40°C to +85°C, compliant with harsh environment standards .

  • Compact Design: Fits into 19" or semi-19" sub-racks (3U card format) .

✅ Easy Integration

  • Compatible with Honeywell 5700 series gas detection systems .

  • Supports field wiring up to 2.5mm² (14 AWG) .

✅ Diagnostics & Control

  • LED indicators for relay status (activated/fault) .

  • Remote reset capability via control system integration .


Technical Specifications

Parameter Specification
Relay Type DPCO (Double-Pole Changeover)
Number of Relays 3
Contact Rating 5A @ 250V AC / 30V DC
Isolation Voltage 2500V (coil-to-contact)
Power Supply 24V DC (typical)
Operating Temp. -40°C to +85°C
Dimensions ~17 cm × 2.5 cm × 11.2 cm (varies by model)
Weight ~0.165 kg

Applications
