GE Multilin 869 Motor Protection Relay

Item NO.:
869
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE Multilin 869 Motor Protection Relay

        Product Overview

        Brand: GE / GE Multilin
        Series: Multilin 8 Series
        Model: 869 Motor Protection Relay
        Product Type: Intelligent Motor Protection Relay
        Function: A multifunctional protection and control relay designed for medium and large induction motors and synchronous motors. It integrates motor protection, control, monitoring, diagnostics, and communication functions to improve motor reliability and reduce downtime.

        Technical Specifications

        Device Type: Digital Motor Protection Relay

        Application: Medium and large horsepower motor protection

        Supported Motors:

        Induction motors

        Synchronous motors

        VFD-driven motors

        High-inertia load motors

        Power Supply

        AC Input: 100–240 VAC, 50/60 Hz

        DC Input: 125–250 VDC

        Operating Range:

        AC: 88–265 VAC

        DC: 88–300 VDC

        Measurement Inputs

        Current Inputs: CT input support

        CT Primary Range: 1–12000 A

        CT Secondary: 1 A / 5 A

        Voltage Input Range: 10–260 V

        RTD Inputs:

        3-wire 100 Ω Platinum RTD

        Temperature range: -40 to +250°C

        Protection Functions

        Thermal overload protection (49)

        Phase overcurrent protection (50/51)

        Ground fault protection (50G/51G)

        Current unbalance protection (46)

        Undervoltage / Overvoltage protection (27/59)

        Underfrequency / Overfrequency protection (81)

        Locked rotor / Jam protection

        Motor starting protection

        Loss of excitation protection

        Stator differential protection

        Breaker failure protection

        Communication Interfaces

        IEC 61850

        Modbus RTU / TCP/IP

        DNP3.0

        IEC 60870-5-104

        Ethernet communication

        Advantages & Features

        Comprehensive Motor Protection

        Integrates multiple protection functions into one relay, providing complete protection for motors against electrical, thermal, and mechanical faults.

        Advanced Motor Diagnostics

        Uses advanced monitoring and motor condition analysis to detect abnormal operating conditions before failures occur.

        High-Speed Fault Response

        Provides fast protection processing to quickly detect faults and reduce motor damage.

        Flexible Communication Capability

        Supports modern industrial communication protocols, allowing easy integration with SCADA, DCS, and power management systems.

        Synchronous Motor Control Support

        Provides dedicated functions for synchronous motor applications, including excitation monitoring and control.

        User-Friendly Configuration

        Supports graphical display, programmable logic, event recording, and simplified commissioning.

        Reliable Industrial Design

        Designed for demanding environments such as power plants, oil & gas facilities, and heavy industrial applications.

        Typical Applications

        Oil & gas production equipment

        Petrochemical plants

        Power generation systems

        Mining equipment

        Cement plants

        Water treatment facilities

        Large pump systems

        Compressor protection systems

        Industrial motor control centers (MCC)

        Precautions

        Confirm motor voltage, current, and CT/PT parameters before installation.

        Ensure relay settings match the protected motor specifications.

        Verify correct wiring of current transformers and voltage transformers.

        Configure protection parameters carefully to avoid false trips.

        Perform relay testing and commissioning after installation.

        Ensure communication settings match the SCADA/DCS system.

        Keep the relay installed in a clean, dry control cabinet environment.
