GE IS215VPROH2B Mark VI Control Module

IS215VPROH2B
IS215VPROH2B

GE IS215VPROH2B Mark VI Control Module

GE IS215VPROH2B Mark VI Control Module

  • Item NO.:

    IS215VPROH2B

  • Payment:

    T/T

  • Price:

    $938/

  • Product Origin:

    USA

  • Color:

    NEW

  • Product weight:

    1.21KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                                                                                                                                                                                                                                                                                                                                            • https://images.openai.com/static-rsc-4/n1cPSFWylO9e-i_WSioB0U680WadFG8nOmBKTs4z0tQNVDxpgNZWueCfwahOe2h4xmPKjitU1dBpcFPBK1p63dAVMfVbix_0s-Q_-8W25ahqjriRexcqvAxWnQ9ZzHS-yk5IMJ-jUJUItjLpvQ_Wv0UgbuSe3ZD6E20Euek9HpbuzOMNR38m0JWVF1pBROKQ?purpose=fullsize

                                                                                                                                                                                                                                                                                                                                                                                                                            • GE IS215VPROH2B Mark VI Control Module

                                                                                                                                                                                                                                                                                                                                                                                                                              Product Overview

                                                                                                                                                                                                                                                                                                                                                                                                                              Brand: GE (General Electric)
                                                                                                                                                                                                                                                                                                                                                                                                                              Model: IS215VPROH2B
                                                                                                                                                                                                                                                                                                                                                                                                                              Product Type: VME Protection Assembly / Turbine Protection Module
                                                                                                                                                                                                                                                                                                                                                                                                                              Series: Mark VI Speedtronic Turbine Control System
                                                                                                                                                                                                                                                                                                                                                                                                                              Application: Gas Turbine / Steam Turbine Emergency Protection

                                                                                                                                                                                                                                                                                                                                                                                                                              The GE IS215VPROH2B is a VPRO Emergency Turbine Protection Board designed for the GE Mark VI Speedtronic turbine control system. It provides an independent emergency overspeed protection function by monitoring turbine speed signals and generating trip commands when unsafe operating conditions are detected.

                                                                                                                                                                                                                                                                                                                                                                                                                              Note: Although often listed as a "Control Module", the IS215VPROH2B is specifically a turbine protection module, not the main turbine control CPU. It works together with terminal boards such as TPRO and TREG to form the emergency trip protection system.

                                                                                                                                                                                                                                                                                                                                                                                                                              Technical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              General Data

                                                                                                                                                                                                                                                                                                                                                                                                                              Parameter Specification
                                                                                                                                                                                                                                                                                                                                                                                                                              Brand GE
                                                                                                                                                                                                                                                                                                                                                                                                                              Model IS215VPROH2B
                                                                                                                                                                                                                                                                                                                                                                                                                              Series Mark VI Speedtronic
                                                                                                                                                                                                                                                                                                                                                                                                                              Product Type VME Protection Assembly
                                                                                                                                                                                                                                                                                                                                                                                                                              Functional Designation VPRO
                                                                                                                                                                                                                                                                                                                                                                                                                              Function Emergency Turbine Protection
                                                                                                                                                                                                                                                                                                                                                                                                                              Installation VME Rack
                                                                                                                                                                                                                                                                                                                                                                                                                              Revision B
                                                                                                                                                                                                                                                                                                                                                                                                                              Technology Surface Mount PCB
                                                                                                                                                                                                                                                                                                                                                                                                                              Application Gas / Steam Turbine Control Systems



                                                                                                                                                                                                                                                                                                                                                                                                                              Main Functions

                                                                                                                                                                                                                                                                                                                                                                                                                              Emergency Overspeed Protection

                                                                                                                                                                                                                                                                                                                                                                                                                              The IS215VPROH2B provides:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Turbine speed monitoring
                                                                                                                                                                                                                                                                                                                                                                                                                              • Emergency overspeed detection
                                                                                                                                                                                                                                                                                                                                                                                                                              • Trip signal processing
                                                                                                                                                                                                                                                                                                                                                                                                                              • Independent turbine shutdown protection
                                                                                                                                                                                                                                                                                                                                                                                                                              • Diagnostic monitoring

                                                                                                                                                                                                                                                                                                                                                                                                                              When turbine speed exceeds programmed safety limits, the module sends a trip command to shut down the turbine safely.

                                                                                                                                                                                                                                                                                                                                                                                                                              Protection Architecture

                                                                                                                                                                                                                                                                                                                                                                                                                              The VPRO system uses a high-reliability protection design:

                                                                                                                                                                                                                                                                                                                                                                                                                              Triple Modular Redundancy (TMR)

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical configuration:



                                                                                                                                                                                                                                                                                                                                                                                                                              VPRO R8
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              Speed → VPRO S8 → Voting Logic → Trip Output
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              VPRO T8


                                                                                                                                                                                                                                                                                                                                                                                                                              Benefits:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Fault tolerance
                                                                                                                                                                                                                                                                                                                                                                                                                              • Continuous turbine protection
                                                                                                                                                                                                                                                                                                                                                                                                                              • High availability operation



                                                                                                                                                                                                                                                                                                                                                                                                                              Input / Output Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              Inputs

                                                                                                                                                                                                                                                                                                                                                                                                                              Supports turbine protection signals including:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Speed pickup signals
                                                                                                                                                                                                                                                                                                                                                                                                                              • Analog current inputs
                                                                                                                                                                                                                                                                                                                                                                                                                              • Thermocouple inputs

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical inputs:

                                                                                                                                                                                                                                                                                                                                                                                                                              • 3 speed/protection input channels



                                                                                                                                                                                                                                                                                                                                                                                                                              Outputs

                                                                                                                                                                                                                                                                                                                                                                                                                              Provides:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Trip relay control signals
                                                                                                                                                                                                                                                                                                                                                                                                                              • Emergency shutdown outputs
                                                                                                                                                                                                                                                                                                                                                                                                                              • Interface to trip solenoids through terminal boards

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical outputs:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Up to 6 output channels



                                                                                                                                                                                                                                                                                                                                                                                                                              Electrical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              Parameter Specification
                                                                                                                                                                                                                                                                                                                                                                                                                              Power Supply 125 V DC nominal
                                                                                                                                                                                                                                                                                                                                                                                                                              Internal Power Generation 5 V DC / 28 V DC
                                                                                                                                                                                                                                                                                                                                                                                                                              Power Consumption Approx. <3 W (board level)
                                                                                                                                                                                                                                                                                                                                                                                                                              Input Current AC 1 A / AC 5 A options
                                                                                                                                                                                                                                                                                                                                                                                                                              Input Burden ≤0.2 VA



                                                                                                                                                                                                                                                                                                                                                                                                                              Communication Interfaces

                                                                                                                                                                                                                                                                                                                                                                                                                              The module provides:

                                                                                                                                                                                                                                                                                                                                                                                                                              • IONet Ethernet communication
                                                                                                                                                                                                                                                                                                                                                                                                                              • RS-232 communication
                                                                                                                                                                                                                                                                                                                                                                                                                              • Diagnostic communication interface
                                                                                                                                                                                                                                                                                                                                                                                                                              • VME backplane connection

                                                                                                                                                                                                                                                                                                                                                                                                                              Front panel includes:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Ethernet/IONet connector
                                                                                                                                                                                                                                                                                                                                                                                                                              • D-shell connectors
                                                                                                                                                                                                                                                                                                                                                                                                                              • LED status indicators



                                                                                                                                                                                                                                                                                                                                                                                                                              Memory & Processor

                                                                                                                                                                                                                                                                                                                                                                                                                              • Processor: Pentium-based processor
                                                                                                                                                                                                                                                                                                                                                                                                                              • Memory: 16 MB DRAM
                                                                                                                                                                                                                                                                                                                                                                                                                              • Flash memory status monitoring
                                                                                                                                                                                                                                                                                                                                                                                                                              • Diagnostic LED indicators



                                                                                                                                                                                                                                                                                                                                                                                                                              Mechanical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              Parameter Specification
                                                                                                                                                                                                                                                                                                                                                                                                                              Mounting VME Rack
                                                                                                                                                                                                                                                                                                                                                                                                                              Board Size Approx. 33 × 17.8 cm
                                                                                                                                                                                                                                                                                                                                                                                                                              Slot Requirement 2 VME slots
                                                                                                                                                                                                                                                                                                                                                                                                                              Connector Type Sub-D connectors
                                                                                                                                                                                                                                                                                                                                                                                                                              Protection Class Rack installation



                                                                                                                                                                                                                                                                                                                                                                                                                              Compatible Equipment

                                                                                                                                                                                                                                                                                                                                                                                                                              Commonly used with:

                                                                                                                                                                                                                                                                                                                                                                                                                              • GE Mark VI Speedtronic turbine control systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • GE TPRO Terminal Board
                                                                                                                                                                                                                                                                                                                                                                                                                              • GE TREG Trip Relay Terminal Board
                                                                                                                                                                                                                                                                                                                                                                                                                              • GE TRPG Trip Terminal Board

                                                                                                                                                                                                                                                                                                                                                                                                                              System configuration:



                                                                                                                                                                                                                                                                                                                                                                                                                              IS215VPROH2B
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              ├── TPRO (Speed Input Interface)
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              └── TREG (Trip Solenoid Interface)




                                                                                                                                                                                                                                                                                                                                                                                                                              Features & Advantages

                                                                                                                                                                                                                                                                                                                                                                                                                              Independent Protection System

                                                                                                                                                                                                                                                                                                                                                                                                                              Operates separately from the main turbine control system for enhanced safety.

                                                                                                                                                                                                                                                                                                                                                                                                                              High Reliability

                                                                                                                                                                                                                                                                                                                                                                                                                              Designed for critical turbine protection applications.

                                                                                                                                                                                                                                                                                                                                                                                                                              Fast Trip Response

                                                                                                                                                                                                                                                                                                                                                                                                                              Provides rapid emergency shutdown protection.

                                                                                                                                                                                                                                                                                                                                                                                                                              Industrial Turbine Grade

                                                                                                                                                                                                                                                                                                                                                                                                                              Suitable for continuous operation in power generation environments.

                                                                                                                                                                                                                                                                                                                                                                                                                              Diagnostic Capability

                                                                                                                                                                                                                                                                                                                                                                                                                              Includes LED status monitoring and communication diagnostics.

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical Applications

                                                                                                                                                                                                                                                                                                                                                                                                                              • Gas turbine protection
                                                                                                                                                                                                                                                                                                                                                                                                                              • Steam turbine protection
                                                                                                                                                                                                                                                                                                                                                                                                                              • Power generation plants
                                                                                                                                                                                                                                                                                                                                                                                                                              • Combined cycle power stations
                                                                                                                                                                                                                                                                                                                                                                                                                              • Industrial turbine systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • Energy facilities

                                                                                                                                                                                                                                                                                                                                                                                                                              Installation Precautions

                                                                                                                                                                                                                                                                                                                                                                                                                              • Confirm compatibility with GE Mark VI system hardware.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Verify VME rack slot configuration.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Check TPRO/TREG terminal board wiring.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Ensure correct 125 V DC supply connection.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Perform turbine protection testing after replacement.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Follow GE Speedtronic commissioning procedures.
