GE IS200SRLYH2A Relay Output Board

IS200SRLYH2A
IS200SRLYH2A

GE IS200SRLYH2A Relay Output Board

GE IS200SRLYH2A Relay Output Board

  • Item NO.:

    IS200SRLYH2A

  • Payment:

    T/T

  • Price:

    $938/

  • Product Origin:

    USA

  • Color:

    NEW

  • Product weight:

    1.21KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                                                                                                                                                                                                                                                                                                                                            • https://images.openai.com/static-rsc-4/9yDd1-dwj3xJSo5PoDyYGRs_OYyHOuDq5uMUyWR4-jKbCO27g-P7dqaO5n4TQ3kAjVtOa8KBRKjZgxnsN7m7oVP46K1Ye9GrX9FDhxtrQoD3sm4VBzvmBXL02qh-VpBmEvHho4pu9PfLXav7XoIk9-yebwoa31uOpawVObKVAXrnEwvPYb8ERVioIzUAyO-e?purpose=fullsize

                                                                                                                                                                                                                                                                                                                                                                                                                            • GE IS200SRLYH2A Relay Output Board

                                                                                                                                                                                                                                                                                                                                                                                                                              Product Overview

                                                                                                                                                                                                                                                                                                                                                                                                                              Brand: GE (General Electric)
                                                                                                                                                                                                                                                                                                                                                                                                                              Model: IS200SRLYH2A
                                                                                                                                                                                                                                                                                                                                                                                                                              Product Type: Simplex Relay Output Terminal Board
                                                                                                                                                                                                                                                                                                                                                                                                                              Series: Mark VI / Mark VIe Speedtronic Turbine Control System
                                                                                                                                                                                                                                                                                                                                                                                                                              Application: Gas Turbine & Steam Turbine Control Systems

                                                                                                                                                                                                                                                                                                                                                                                                                              The GE IS200SRLYH2A is a Simplex Relay Output Terminal Board (SRLY) designed for the GE Mark VI turbine control system. It provides 12 Form-C relay output circuits and interfaces with GE I/O packs such as PDOA/YDOA for turbine control signal output.

                                                                                                                                                                                                                                                                                                                                                                                                                              It is mainly used for controlling external devices such as:

                                                                                                                                                                                                                                                                                                                                                                                                                              • Solenoid valves
                                                                                                                                                                                                                                                                                                                                                                                                                              • Contactors
                                                                                                                                                                                                                                                                                                                                                                                                                              • Actuators
                                                                                                                                                                                                                                                                                                                                                                                                                              • Alarm relays
                                                                                                                                                                                                                                                                                                                                                                                                                              • Turbine auxiliary equipment

                                                                                                                                                                                                                                                                                                                                                                                                                              Technical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              Parameter Specification
                                                                                                                                                                                                                                                                                                                                                                                                                              Brand GE
                                                                                                                                                                                                                                                                                                                                                                                                                              Model IS200SRLYH2A
                                                                                                                                                                                                                                                                                                                                                                                                                              Series Mark VI Speedtronic
                                                                                                                                                                                                                                                                                                                                                                                                                              Product Type Simplex Relay Output Terminal Board
                                                                                                                                                                                                                                                                                                                                                                                                                              Function Relay output interface
                                                                                                                                                                                                                                                                                                                                                                                                                              Relay Channels 12 channels
                                                                                                                                                                                                                                                                                                                                                                                                                              Relay Type Form-C relay contacts
                                                                                                                                                                                                                                                                                                                                                                                                                              Terminal Points 48 customer terminals
                                                                                                                                                                                                                                                                                                                                                                                                                              Mounting Control cabinet / Mark VI rack
                                                                                                                                                                                                                                                                                                                                                                                                                              Technology Surface Mount PCB
                                                                                                                                                                                                                                                                                                                                                                                                                              Application Turbine control system



                                                                                                                                                                                                                                                                                                                                                                                                                              Main Functions

                                                                                                                                                                                                                                                                                                                                                                                                                              Relay Output Control

                                                                                                                                                                                                                                                                                                                                                                                                                              The IS200SRLYH2A provides:

                                                                                                                                                                                                                                                                                                                                                                                                                              • 12 independent relay output circuits
                                                                                                                                                                                                                                                                                                                                                                                                                              • Relay contact switching
                                                                                                                                                                                                                                                                                                                                                                                                                              • External device control
                                                                                                                                                                                                                                                                                                                                                                                                                              • Output status feedback to I/O processor

                                                                                                                                                                                                                                                                                                                                                                                                                              Each relay uses an isolated contact pair for feedback to the connected GE I/O pack.

                                                                                                                                                                                                                                                                                                                                                                                                                              Hardware Features

                                                                                                                                                                                                                                                                                                                                                                                                                              Relay Configuration

                                                                                                                                                                                                                                                                                                                                                                                                                              The board includes:

                                                                                                                                                                                                                                                                                                                                                                                                                              • 12 relay devices
                                                                                                                                                                                                                                                                                                                                                                                                                              • Terminal block TB1
                                                                                                                                                                                                                                                                                                                                                                                                                              • Relay driver circuits
                                                                                                                                                                                                                                                                                                                                                                                                                              • Signal conditioning components

                                                                                                                                                                                                                                                                                                                                                                                                                              The relays are arranged in three groups of four relays.

                                                                                                                                                                                                                                                                                                                                                                                                                              Terminal Interface

                                                                                                                                                                                                                                                                                                                                                                                                                              Features:

                                                                                                                                                                                                                                                                                                                                                                                                                              • 48 customer connection terminals
                                                                                                                                                                                                                                                                                                                                                                                                                              • Supports external field wiring
                                                                                                                                                                                                                                                                                                                                                                                                                              • Compatible with GE Mark VI terminal board architecture

                                                                                                                                                                                                                                                                                                                                                                                                                              The board accepts:

                                                                                                                                                                                                                                                                                                                                                                                                                              • PDOA I/O Pack
                                                                                                                                                                                                                                                                                                                                                                                                                              • YDOA I/O Pack



                                                                                                                                                                                                                                                                                                                                                                                                                              Electrical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              Parameter Specification
                                                                                                                                                                                                                                                                                                                                                                                                                              Relay Output Type Form-C (Changeover Contact)
                                                                                                                                                                                                                                                                                                                                                                                                                              Number of Outputs 12
                                                                                                                                                                                                                                                                                                                                                                                                                              Maximum Current Approx. 5 A (terminal circuit limitation)
                                                                                                                                                                                                                                                                                                                                                                                                                              Voltage Capability Up to 250 VAC clearance design
                                                                                                                                                                                                                                                                                                                                                                                                                              Typical Applications 24 VDC / 125 VDC / AC relay switching



                                                                                                                                                                                                                                                                                                                                                                                                                              System Architecture

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical connection:



                                                                                                                                                                                                                                                                                                                                                                                                                              GE Mark VI Controller
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              PDOA / YDOA I/O Pack
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              IS200SRLYH2A
                                                                                                                                                                                                                                                                                                                                                                                                                              Relay Output Board
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              External Field Devices
                                                                                                                                                                                                                                                                                                                                                                                                                              │
                                                                                                                                                                                                                                                                                                                                                                                                                              ├── Solenoid Valves
                                                                                                                                                                                                                                                                                                                                                                                                                              ├── Contactors
                                                                                                                                                                                                                                                                                                                                                                                                                              ├── Alarms
                                                                                                                                                                                                                                                                                                                                                                                                                              └── Actuators




                                                                                                                                                                                                                                                                                                                                                                                                                              Compatible Equipment

                                                                                                                                                                                                                                                                                                                                                                                                                              Commonly used with:

                                                                                                                                                                                                                                                                                                                                                                                                                              • GE Mark VI Speedtronic systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • GE Mark VIe turbine control systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • PDOA I/O Pack
                                                                                                                                                                                                                                                                                                                                                                                                                              • YDOA I/O Pack
                                                                                                                                                                                                                                                                                                                                                                                                                              • GE VME control racks



                                                                                                                                                                                                                                                                                                                                                                                                                              Features & Advantages

                                                                                                                                                                                                                                                                                                                                                                                                                              Reliable Relay Switching

                                                                                                                                                                                                                                                                                                                                                                                                                              Provides stable output switching for turbine auxiliary equipment.

                                                                                                                                                                                                                                                                                                                                                                                                                              Modular Turbine Control Design

                                                                                                                                                                                                                                                                                                                                                                                                                              Designed for GE Speedtronic modular architecture.

                                                                                                                                                                                                                                                                                                                                                                                                                              Easy Maintenance

                                                                                                                                                                                                                                                                                                                                                                                                                              Terminal board design allows convenient field wiring and replacement.

                                                                                                                                                                                                                                                                                                                                                                                                                              Industrial Safety Application

                                                                                                                                                                                                                                                                                                                                                                                                                              Suitable for continuous-duty turbine control environments.

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical Applications

                                                                                                                                                                                                                                                                                                                                                                                                                              • Gas turbine control
                                                                                                                                                                                                                                                                                                                                                                                                                              • Steam turbine control
                                                                                                                                                                                                                                                                                                                                                                                                                              • Power generation plants
                                                                                                                                                                                                                                                                                                                                                                                                                              • Combined cycle power stations
                                                                                                                                                                                                                                                                                                                                                                                                                              • Industrial energy systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • Turbine auxiliary control

                                                                                                                                                                                                                                                                                                                                                                                                                              Installation Precautions

                                                                                                                                                                                                                                                                                                                                                                                                                              • Confirm compatibility with Mark VI / Mark VIe system configuration.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Verify correct PDOA/YDOA I/O pack installation.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Check relay voltage and current ratings before connection.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Ensure correct field wiring polarity.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Follow GE turbine control maintenance procedures.
                                                                                                                                                                                                                                                                                                                                                                                                                              • Perform I/O testing after replacement.

The structure and details of the product：
