GE IC695ALG616-EA Analog Input Module

Item NO.:
IC695ALG616-EA
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE IC695ALG616-EA PACSystems RX3i Analog Input Module

        Product Overview

        Brand: GE Fanuc / Emerson
        Series: PACSystems RX3i
        Model: IC695ALG616-EA
        Product Type: Analog Input Module
        Function: A configurable non-isolated analog input module designed for GE PACSystems RX3i PLC systems. It collects voltage and current signals from field devices, converts analog signals into digital data, and transfers process information to the PLC CPU for monitoring and control.

        Technical Specifications

        Module Type: Analog Input Module

        Series Compatibility: PACSystems RX3i

        Module Version: EA Revision

        Input Channels:

        16 single-ended inputs

        8 differential inputs

        Input Type: Configurable voltage/current analog input

        Input Signal Range:

        Current Input

        0–20 mA

        4–20 mA

        ±20 mA

        Voltage Input

        ±10 VDC

        0–10 VDC

        ±5 VDC

        0–5 VDC

        1–5 VDC

        Resolution: 24-bit ADC conversion

        Data Format:

        IEEE 32-bit floating point

        16-bit integer format

        Input Filter Settings:

        8 Hz

        12 Hz

        16 Hz

        40 Hz

        200 Hz

        500 Hz

        Backplane Installation: RX3i Universal Backplane

        Slot Occupation: 1 slot

        Power Consumption:

        3.3 VDC: 450 mA

        5 VDC: 600 mA

        Operating Temperature: 0°C to 60°C

        Terminal Block Compatibility:

        IC694TBB032

        IC694TBB132

        IC694TBS032

        IC694TBS132

        Advantages & Features

        High-Precision Signal Acquisition

        Uses a 24-bit ADC converter to provide accurate measurement of industrial analog signals for reliable process monitoring.

        Flexible Input Configuration

        Each channel can be configured for different voltage or current signal ranges, allowing connection with various sensors and transmitters.

        High Channel Density

        Supports up to 16 single-ended or 8 differential inputs in one compact module, saving control cabinet space.

        Software Configurable

        Configuration is completed through PLC programming software without hardware jumper settings, simplifying installation and maintenance.

        Advanced Diagnostic Functions

        Supports channel fault reporting, alarm monitoring, open-circuit detection, and signal status diagnostics.

        Reliable RX3i Integration

        Designed for GE PACSystems RX3i universal backplanes, providing stable communication with CPU and other I/O modules.

        Typical Applications

        Industrial automation systems

        Process control systems

        Oil & gas equipment

        Chemical processing plants

        Power generation systems

        Water treatment facilities

        Temperature, pressure, and flow monitoring

        Factory production lines

        Machine automation systems

        Precautions

        Confirm compatibility with GE PACSystems RX3i Universal Backplane before installation.

        Verify analog input signal type and range before wiring.

        Use shielded cables for analog signal connections to reduce noise interference.

        Ensure correct wiring polarity for differential inputs.

        Configure channel parameters correctly in PLC software.

        Avoid exceeding input voltage/current limits.

        Disconnect power before installing or removing the module.

        Perform calibration and signal testing after replacement.
