GE IC694MDL754 Series 90-30 Digital Output Module

IC694MDL754
IC694MDL754

GE IC694MDL754 Series 90-30 Digital Output Module

GE IC694MDL754 Series 90-30 Digital Output Module

  • Item NO.:

    IC694MDL754

  • Payment:

    T/T

  • Price:

    $938/

  • Product Origin:

    USA

  • Color:

    NEW

  • Product weight:

    1.21KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                                                                                                                                                                                                                                                                                                                                            • https://images.openai.com/static-rsc-4/YUHRAVxFZu2ValAwMq9CVh7eHqek4e8JTkKd6fpR1lWQsSTiH8H_gxuppVG26_e9WyHlto1NNeKBy5QJcW-9ldOpGxF3NDn7AoQj1kgjZ31Yl0YDZqtWYFnhoiwsoxaGTzPIIejdClOTO_y-w7tadfT2Bdvnu4twBiLtqdbWjVIWRhnVy2h4W07X0fg-8dxV?purpose=fullsize

                                                                                                                                                                                                                                                                                                                                                                                                                            • Product Overview
                                                                                                                                                                                                                                                                                                                                                                                                                              The GE IC694MDL754 is a 32-point 12/24 VDC Positive Logic Digital Output Module for the GE Fanuc PACSystems RX3i platform. It provides sourcing-type outputs for controlling external DC loads and features electronic short-circuit protection (ESCP).

                                                                                                                                                                                                                                                                                                                                                                                                                              Technical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              • Model: IC694MDL754
                                                                                                                                                                                                                                                                                                                                                                                                                              • Series: PACSystems RX3i
                                                                                                                                                                                                                                                                                                                                                                                                                              • Type: Digital/Discrete Output Module
                                                                                                                                                                                                                                                                                                                                                                                                                              • Rated Voltage: 12/24 VDC nominal
                                                                                                                                                                                                                                                                                                                                                                                                                              • Output Voltage Range: 10.2–30 VDC
                                                                                                                                                                                                                                                                                                                                                                                                                              • Outputs: 32 points
                                                                                                                                                                                                                                                                                                                                                                                                                              • Output Configuration: 2 isolated groups × 16 points
                                                                                                                                                                                                                                                                                                                                                                                                                              • Output Current: 0.75 A per point
                                                                                                                                                                                                                                                                                                                                                                                                                              • Logic: Positive logic / sourcing
                                                                                                                                                                                                                                                                                                                                                                                                                              • Backplane Consumption: 300 mA max from 5 VDC bus
                                                                                                                                                                                                                                                                                                                                                                                                                              • Response Time: 0.5 ms max. ON/OFF
                                                                                                                                                                                                                                                                                                                                                                                                                              • Isolation: 250 VAC continuous; 1500 VAC for 1 minute
                                                                                                                                                                                                                                                                                                                                                                                                                              • Protection: Short-circuit, overcurrent, and overtemperature protection with automatic recovery

                                                                                                                                                                                                                                                                                                                                                                                                                              Advantages & Features

                                                                                                                                                                                                                                                                                                                                                                                                                              • High-density 32-point digital output
                                                                                                                                                                                                                                                                                                                                                                                                                              • Supports both 12 VDC and 24 VDC loads
                                                                                                                                                                                                                                                                                                                                                                                                                              • Built-in electronic short-circuit protection
                                                                                                                                                                                                                                                                                                                                                                                                                              • Fast 0.5 ms output response
                                                                                                                                                                                                                                                                                                                                                                                                                              • Two electrically isolated output groups
                                                                                                                                                                                                                                                                                                                                                                                                                              • Suitable for reliable industrial control applications

                                                                                                                                                                                                                                                                                                                                                                                                                              Applications

                                                                                                                                                                                                                                                                                                                                                                                                                              • PLC machine control
                                                                                                                                                                                                                                                                                                                                                                                                                              • Industrial automation
                                                                                                                                                                                                                                                                                                                                                                                                                              • Solenoid and relay control
                                                                                                                                                                                                                                                                                                                                                                                                                              • Motor/control-panel interfaces
                                                                                                                                                                                                                                                                                                                                                                                                                              • Manufacturing and process equipment
                                                                                                                                                                                                                                                                                                                                                                                                                            •

The structure and details of the product：
