GE IC694MDL660-EC PACSystems RX3i Digital Input Module

IC694MDL660-EC
IC694MDL660-EC

GE IC694MDL660-EC PACSystems RX3i Digital Input Module

GE IC694MDL660-EC PACSystems RX3i Digital Input Module

  • Item NO.:

    IC694MDL660-EC

  • Payment:

    T/T

  • Price:

    $938/

  • Product Origin:

    USA

  • Color:

    NEW

  • Product weight:

    1.21KG

  • Lead Time:

    In stock
Inquire Now

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

                                                                                                                                                                                                                                                                                                                                                                                                                            • GE / Emerson IC694MDL660 PACSystems RX3i Digital Input Module

                                                                                                                                                                                                                                                                                                                                                                                                                              The GE IC694MDL660 is a PACSystems RX3i 24 VDC 32-point positive/negative logic discrete input module. It provides 32 digital input points arranged in four isolated groups of eight and supports selectable input filter times. Emerson currently lists the IC694MDL660 as an RX3i DC voltage input module.

                                                                                                                                                                                                                                                                                                                                                                                                                              Key Technical Specifications

                                                                                                                                                                                                                                                                                                                                                                                                                              Parameter Specification
                                                                                                                                                                                                                                                                                                                                                                                                                              Brand GE / Emerson
                                                                                                                                                                                                                                                                                                                                                                                                                              Model IC694MDL660
                                                                                                                                                                                                                                                                                                                                                                                                                              Product Type PACSystems RX3i Digital Input Module
                                                                                                                                                                                                                                                                                                                                                                                                                              Input Type DC Voltage / Discrete Input
                                                                                                                                                                                                                                                                                                                                                                                                                              Rated Voltage 24 VDC
                                                                                                                                                                                                                                                                                                                                                                                                                              Input Voltage Range 0–30 VDC
                                                                                                                                                                                                                                                                                                                                                                                                                              Number of Inputs 32 points
                                                                                                                                                                                                                                                                                                                                                                                                                              Logic Positive / Negative Logic
                                                                                                                                                                                                                                                                                                                                                                                                                              Input Arrangement 4 isolated groups × 8 inputs
                                                                                                                                                                                                                                                                                                                                                                                                                              ON-State Voltage 11.5–30 VDC
                                                                                                                                                                                                                                                                                                                                                                                                                              OFF-State Voltage 0–5 VDC
                                                                                                                                                                                                                                                                                                                                                                                                                              Typical Input Current 7.0 mA per point
                                                                                                                                                                                                                                                                                                                                                                                                                              Input Filter 0.5, 1, 2, 5, 10, 50 or 100 ms
                                                                                                                                                                                                                                                                                                                                                                                                                              Field-to-Backplane Isolation 250 VAC continuous / 1500 VAC for 1 minute
                                                                                                                                                                                                                                                                                                                                                                                                                              Group-to-Group Isolation 250 VAC continuous / 1500 VAC for 1 minute
                                                                                                                                                                                                                                                                                                                                                                                                                              Backplane Current 300 mA @ 5 VDC
                                                                                                                                                                                                                                                                                                                                                                                                                              Mounting Panel / DIN Rail
                                                                                                                                                                                                                                                                                                                                                                                                                              Terminal Block Ordered separately

                                                                                                                                                                                                                                                                                                                                                                                                                              The module's filter time is selectable, allowing the input response to be configured from 0.5 ms to 100 ms.

                                                                                                                                                                                                                                                                                                                                                                                                                              Advantages & Features

                                                                                                                                                                                                                                                                                                                                                                                                                              • 32 high-density digital inputs
                                                                                                                                                                                                                                                                                                                                                                                                                              • Supports both positive and negative logic
                                                                                                                                                                                                                                                                                                                                                                                                                              • Four electrically isolated groups of eight inputs
                                                                                                                                                                                                                                                                                                                                                                                                                              • Wide 0–30 VDC input range
                                                                                                                                                                                                                                                                                                                                                                                                                              • Selectable input filtering
                                                                                                                                                                                                                                                                                                                                                                                                                              • Individual LED indicators for input status
                                                                                                                                                                                                                                                                                                                                                                                                                              • Optical isolation between field and backplane
                                                                                                                                                                                                                                                                                                                                                                                                                              • Designed for PACSystems RX3i control systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • Suitable for high-density industrial discrete I/O applications

                                                                                                                                                                                                                                                                                                                                                                                                                              Typical Applications

                                                                                                                                                                                                                                                                                                                                                                                                                              • Industrial automation
                                                                                                                                                                                                                                                                                                                                                                                                                              • Machine control
                                                                                                                                                                                                                                                                                                                                                                                                                              • Factory automation
                                                                                                                                                                                                                                                                                                                                                                                                                              • Conveyor systems
                                                                                                                                                                                                                                                                                                                                                                                                                              • Motor and equipment status monitoring
                                                                                                                                                                                                                                                                                                                                                                                                                              • Switch and sensor signal acquisition
                                                                                                                                                                                                                                                                                                                                                                                                                              • Process control
                                                                                                                                                                                                                                                                                                                                                                                                                              • PACSystems RX3i PLC systems
