GE IC200CHS022 VersaMax Terminal Base Module

Item NO.:
IC200CHS022
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE IC200CHS022 VersaMax Terminal Base Module

        Product Overview

        Brand: GE Fanuc / Emerson
        Series: VersaMax
        Model: IC200CHS022
        Product Type: Compact I/O Carrier / Terminal Base Module
        Function: Provides mechanical mounting, field wiring terminals, and backplane communication connections for VersaMax I/O modules. It is used as the installation base for VersaMax PLC I/O modules, allowing quick module replacement without removing field wiring.

        Technical Specifications

        Module Type: Compact I/O Carrier / Terminal Base

        Series Compatibility: GE VersaMax PLC System

        Mounting Type:

        35 mm DIN rail mounting

        Panel mounting

        Terminal Type: Local box-style screw terminals

        Number of Terminals: 36 terminals

        A1–A18

        B1–B18

        Supported I/O Module: 1 VersaMax I/O module

        Wiring Type: Integrated field wiring termination

        Voltage Rating: Up to 264 VAC

        Current Rating:

        2 A per terminal point

        8 A per power/ground segment

        Transient Voltage Protection: Up to 300 VAC

        Wire Size:

        Single wire: AWG #14 to AWG #22

        Two wires: Up to AWG #18

        Dimensions: Approx. 66.8 × 163.5 × 70 mm

        Operating Temperature: 0°C to 60°C

        Compatible System: VersaMax I/O modules and NIU systems

        Advantages & Features

        Integrated Terminal Design

        Combines I/O module mounting and field wiring terminals into one compact unit, reducing cabinet space requirements.

        Easy Module Replacement

        Allows I/O modules to be removed or replaced without disconnecting field wiring, reducing maintenance time and system downtime.

        Reliable Backplane Communication

        Provides stable electrical connection between VersaMax I/O modules and the control system.

        Flexible Installation

        Supports DIN rail and panel mounting, suitable for different industrial cabinet layouts.

        High Wiring Flexibility

        36 integrated screw terminals provide convenient connection for various field devices.

        Industrial Durability

        Designed for factory automation and process control environments with reliable mechanical and electrical performance.

        Typical Applications

        Industrial PLC control systems

        Factory automation equipment

        Machine control systems

        Manufacturing production lines

        Packaging machinery

        Material handling systems

        Process monitoring systems

        Remote I/O stations

        Precautions

        Confirm compatibility with the GE VersaMax I/O module before installation.

        Ensure correct terminal wiring according to the module type.

        Check voltage and current ratings before connecting field devices.

        Disconnect power before installing or removing modules.

        Ensure DIN rail grounding is properly connected for EMC protection.

        Avoid installation in areas with excessive moisture, dust, or vibration.

        Verify I/O communication status after installation.
