GE DS200DCFBG1B Drive Control Board

Item NO.:
DS200DCFBG1B
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE DS200DCFBG1B Drive Control Board

        Product Overview

        Brand: GE General Electric
        Series: Mark V DS200
        Model: DS200DCFBG1B
        Product Type: DC Power Supply & Feedback Board / Drive Control Board
        Function: The DS200DCFBG1B is a power supply and feedback interface board used in GE Mark V drive control systems. It provides control-level DC power, motor feedback signals, and monitoring functions for GE drive applications. It is mainly used in DC2000, CB2000, EX2000, FC2000, GF2000, ME2000, and AC2000 drive systems.

        Technical Specifications

        Manufacturer: GE General Electric

        Series: Mark V DS200

        Model: DS200DCFBG1B

        Board Type: DC Power Supply / Feedback Board

        Application: Drive Control System Interface Board

        Power Input

        Input Voltage:

        38 VAC

        115 VAC

        24 VDC (depending on system configuration)

        Output Power Supplies:

        +24 VDC output

        -24 VDC output

        +15 VDC / -15 VDC outputs

        +5 VDC control power output

        Output Ratings:

        +24 VDC: 3 A

        -24 VDC: 1 A

        ±15 VDC: 0.8 A each

        +5 VDC: 4 A

        Feedback & Monitoring Functions

        Motor armature current feedback

        Motor armature voltage feedback

        Motor field current feedback

        AC line current monitoring

        AC line voltage magnitude monitoring

        Phase sequence monitoring

        Motor voltage attenuation feedback

        Hardware Features

        Configurable jumpers:

        12 onboard jumpers

        Additional jumper options depending on revision

        DIP Switches:

        7 programmable DIP switches

        Indicators:

        CR51 LED fuse status indicator

        CR55 LED fuse status indicator

        LT1 neon fuse indicator

        Test Points:

        Multiple voltage monitoring test points

        Protection:

        Fuse protection for power outputs

        Short-circuit protection

        Advantages & Features

        Integrated Power & Feedback Function

        Combines power supply generation and drive feedback monitoring functions into one board, reducing system complexity.

        Reliable Drive Control

        Provides accurate voltage and current feedback signals required for stable motor speed and torque control.

        Multiple Drive Compatibility

        Compatible with multiple GE Mark V drive platforms, offering flexible replacement options.

        Advanced Monitoring Capability

        Monitors critical motor and power signals to help improve system diagnostics and maintenance efficiency.

        Built-In Protection Design

        Includes fuse protection, diagnostic LEDs, and monitoring circuits to improve system reliability.

        Industrial Grade Reliability

        Designed for continuous operation in demanding industrial drive and turbine control environments.

        Typical Applications

        GE Mark V turbine control systems

        Industrial DC drive systems

        Motor speed control equipment

        Power generation facilities

        Gas turbine auxiliary systems

        Large industrial machinery

        Steel mills

        Paper manufacturing equipment

        Mining equipment

        Precautions

        Confirm the exact board revision before replacement.

        Verify jumper and DIP switch settings match the original board.

        Disconnect power completely before installation.

        Allow capacitors to discharge before handling the board.

        Check all cable connections carefully during replacement.

        Perform parameter adjustment after installation if required.

        Verify feedback signals and power outputs before system startup.
