• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • GE CR123-H317A Control Relay

                                                                                                                                                                                  Product Description

                                                                                                                                                                                  GE CR123H317A is not a control relay. It is a thermal overload heater unit (overload relay heater element) designed for GE CR101H / CR101Y Series Manual Motor Starters. It provides motor overload protection by sensing excessive current and triggering the starter protection mechanism.

                                                                                                                                                                                  This component is installed inside a motor starter/overload relay assembly and is used to protect small motors from overheating caused by overload conditions.

                                                                                                                                                                                  ---

                                                                                                                                                                                  Technical Parameters

                                                                                                                                                                                  • Brand: GE (General Electric)
                                                                                                                                                                                  • Model: CR123H317A
                                                                                                                                                                                  • Product Type: Thermal Overload Heater Unit
                                                                                                                                                                                  • Series: CR123H
                                                                                                                                                                                  • Compatible Equipment:
                                                                                                                                                                                    • GE CR101H Manual Motor Starter
                                                                                                                                                                                    • GE CR101Y Manual Motor Starter
                                                                                                                                                                                  • Full Load Current Rating: 2.76 A
                                                                                                                                                                                  • Motor Application: Approx. 3/4 HP – 1 HP
                                                                                                                                                                                  • Voltage Rating: 115 / 230 / 277 VAC
                                                                                                                                                                                  • Frequency: 25/60 Hz
                                                                                                                                                                                  • Trip Type: Standard Thermal Overload
                                                                                                                                                                                  • Installation Type: Motor starter overload relay heater element
                                                                                                                                                                                  • Application: Single-phase motor protection

                                                                                                                                                                                  ---

                                                                                                                                                                                  Advantages & Features

                                                                                                                                                                                  • Original GE industrial motor protection component
                                                                                                                                                                                  • Provides reliable thermal overload protection
                                                                                                                                                                                  • Protects motors from excessive current and overheating
                                                                                                                                                                                  • Designed specifically for CR101 series starters
                                                                                                                                                                                  • Compact design for easy replacement
                                                                                                                                                                                  • Improves motor operation safety and reliability
                                                                                                                                                                                  • Suitable for industrial electrical control applications

                                                                                                                                                                                  ---

                                                                                                                                                                                  Applications

                                                                                                                                                                                  • Motor control panels
                                                                                                                                                                                  • Industrial pumps
                                                                                                                                                                                  • Fans and blowers
                                                                                                                                                                                  • Small machinery equipment
                                                                                                                                                                                  • HVAC systems
                                                                                                                                                                                  • Factory automation equipment
                                                                                                                                                                                  • Electrical distribution systems

                                                                                                                                                                                  ---

                                                                                                                                                                                  Notes

                                                                                                                                                                                  • CR123H317A is a thermal heater element, not a PLC relay or electronic control module.
                                                                                                                                                                                  • It must be matched with the correct GE CR101H/CR101Y starter model.
                                                                                                                                                                                  • Confirm motor full-load current before selecting the heater rating.
                                                                                                                                                                                  • Replace only with the same specification heater unit to maintain overload protection performance.

The structure and details of the product：
