GE 469-P5-HI-A20-T-H Motor Protection Relay

Item NO.:
469-P5-HI-A20-T-H
Payment:
T/T
Price:
$938/
Product Origin:
USA
Color:
NEW
Product weight:
1.21KG
Lead Time:
In stock

- - - - GE MULTILIN 469-P5-HI-A20-T-H Motor Protection Relay

        Product Overview

        The GE Multilin 469-P5-HI-A20-T-H is a multifunctional motor protection and management relay designed for medium- and large-size motors. It combines motor protection, monitoring, control, metering, and communication functions. The P5 version uses 5 A phase CT secondaries, HI indicates high-range control power, A20 provides 4–20 mA analog outputs, T adds Ethernet, and H provides conformal coating for harsh environments.

        Technical Specifications

        Model: 469-P5-HI-A20-T-H

        Series: GE Multilin 469

        Type: Motor Protection / Motor Management Relay

        Phase CT Input: 5 A secondary

        Control Power: 90–300 VDC or 70–265 VAC, 48–62 Hz

        Analog Outputs: Four 4–20 mA

        Communication: RS-232 / RS-485, Modbus RTU

        Ethernet: 10Base-T, Modbus TCP/IP

        Display: Enhanced front panel

        Protection: Thermal overload, overcurrent, ground fault, phase unbalance, under/overvoltage, under/overfrequency, jam and stall protection

        Motor Monitoring: Current, voltage, power, energy, power factor, thermal capacity and motor starts

        Environment: Conformal coating for harsh chemical environments

        Operating Temperature: Approximately −20°C to +70°C

        Configuration Software: EnerVista 469 Setup

        Advantages & Features

        Comprehensive protection for medium and large motors

        Advanced thermal model and multiple RTD inputs

        Accurate motor electrical and thermal monitoring

        Integrated Ethernet communication

        Four 4–20 mA analog outputs for monitoring and control

        Programmable protection and control functions

        Harsh-environment conformal coating

        Drawout construction helps simplify maintenance and replacement

        Applications

        Medium- and high-voltage motor protection

        Oil & Gas

        Petrochemical and Chemical Processing

        Power Generation

        Water & Wastewater

        Mining and Metals

        Pulp & Paper

        Industrial Manufacturing

        Pumps, compressors, fans and large rotating machinery

        Important Notes

        Verify the 5 A CT secondary rating before installation.

        Confirm the control-power requirement: 90–300 VDC or 70–265 VAC.

        CT wiring and polarity must be correct to ensure accurate protection and metering.

        Confirm Ethernet and communication settings before connecting to the control network.

        Protection parameters should be configured according to the motor's nameplate and application.

        High-voltage motor protection equipment should be installed and commissioned by qualified personnel.

        The H suffix indicates conformal coating for harsh environments; it should not be confused with the standard version.
