Product Overview

The Allen-Bradley 5069-RTB18-SPRING is a Compact 5000 I/O Removable Terminal Block (RTB) with spring clamp connection technology. It is designed for CompactLogix 5380, Compact GuardLogix 5380, and CompactLogix 5480 systems, providing a reliable wiring interface between field devices and Compact 5000 I/O modules.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 5069-RTB18-SPRING
• Product Type: Removable Terminal Block
• Series: Compact 5000 I/O
• Terminal Type: Spring Clamp Terminal
• Number of Pins: 18 Pins
• Rated Voltage: Up to 300 VAC
• Rated Current: 10 A
• Wire Size: 0.5–1.5 mm² (22–16 AWG)
• Wire Type: Solid or stranded copper wire
• Temperature Rating: Up to 105 °C
• Mounting: Compact 5000 I/O Module Installation
• Package Quantity: 1 pcs
• Country of Origin: Germany

Advantages & Features

• Tool-free spring clamp connection for faster wiring
• Provides secure and vibration-resistant connections
• Removable design simplifies module replacement and maintenance
• Designed specifically for Compact 5000 I/O systems
• Compact structure saves cabinet space
• Reduces wiring errors and improves installation efficiency

Applications

• CompactLogix PLC systems
• Factory automation equipment
• Industrial control cabinets
• Machine control systems
• Distributed I/O applications
• Manufacturing production lines

Important Notes

• Confirm compatibility with the specific 5069 I/O module before installation
• Ensure correct wire size and stripping length
• Check terminal connection before powering the system
• Use proper grounding and wiring practices
• Disconnect power before replacement or maintenance
