Product Overview

The Allen-Bradley 5069-OB16K is a Compact 5000 I/O 16-Channel 24V DC Digital Output Module designed for CompactLogix 5380/5480 control systems. It provides reliable sourcing output control for industrial actuators, valves, relays, and other field devices. The K version features conformal coating, offering improved protection in harsh industrial environments.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 5069-OB16K
• Product Type: Digital Output Module
• Series: Compact 5000 I/O
• Output Channels: 16 Channels
• Output Type: 24V DC Source Output (PNP)
• Output Voltage: 12/24 VDC
• Maximum Output Current: 0.5 A per channel
• Maximum Module Current: 8 A
• Isolation Voltage: 250 VAC continuous
• Indicators:
  • Module Status LED
  • 16 × I/O Status LEDs
• Mounting: DIN Rail Mount
• Coating: Conformal Coated
• Compatible Controllers:
  • CompactLogix 5380 Series
  • CompactLogix 5480 Series

Advantages & Features

• 16-channel high-density digital output design
• Compact size saves control cabinet space
• Fast backplane communication performance
• Supports high-speed output control applications
• Conformal coating improves resistance to moisture, dust, and industrial contaminants
• LED indicators simplify troubleshooting and maintenance
• Reliable operation for demanding automation environments

Applications

• Factory automation systems
• PLC control panels
• Solenoid valve control
• Motor starter control
• Conveyor systems
• Packaging machinery
• Robotics and machine automation
• Process control systems

Important Notes

• Confirm compatibility with Compact 5000 I/O system before installation
• Verify 24VDC power supply and wiring configuration
• Do not exceed the rated output current
• Ensure proper grounding and field power connection
• Disconnect power before installation or maintenance
