Allen-Bradley 5069-IB16K Digital Input Module

Allen-Bradley 5069-IB16K Digital Input Module

Product Overview

The Allen-Bradley 5069-IB16K is a Compact 5000 I/O 16-Channel 24V DC Digital Input Module designed for CompactLogix and Compact 5000 I/O systems. It provides reliable digital signal acquisition for industrial automation applications and features a conformal coated design for improved protection in harsh environments.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 5069-IB16K
• Product Type: Digital Input Module
• Series: Compact 5000 I/O
• Input Channels: 16 Channels
• Input Type: DC Sink Input
• Rated Input Voltage: 24 VDC
• Input Voltage Range: 10–32 VDC
• Input Current: Approx. 4 mA per channel
• Module Width: Compact design (22 mm)
• Coating: Conformal Coated
• Communication: Compact 5000 backplane
• Mounting: DIN Rail Mount
• Operating Temperature: 0…60 °C

Advantages & Features

• 16-channel high-density digital input design
• Compact size saves cabinet installation space
• Fast backplane communication performance
• Conformal coating improves resistance to moisture, dust, and industrial contaminants
• LED status indicators simplify troubleshooting
• Reliable signal monitoring for automation systems
• Compatible with CompactLogix 5380/5480 control platforms

Applications

• Factory automation systems
• PLC control cabinets
• Machine monitoring equipment
• Packaging machinery
• Material handling systems
• Manufacturing production lines
• Process automation systems

Important Notes

• Confirm compatibility with the Compact 5000 I/O system before installation
• Verify 24VDC input wiring configuration
• Ensure correct module addressing and configuration
• Use proper grounding and shielding methods
• Disconnect power before installation or maintenance
