Allen-Bradley 1783-USP5T Stratix Unmanaged Ethernet Switch

Allen-Bradley 1783-USP5T Stratix Unmanaged Ethernet Switch

Product Overview

The Allen-Bradley 1783-USP5T is a Stratix 2100 Series unmanaged Ethernet switch designed for industrial Ethernet communication networks. It provides simple and reliable Layer 2 Ethernet switching without configuration requirements, making it ideal for connecting PLCs, HMIs, remote I/O, and industrial devices.

Main Specifications

• Manufacturer: Allen-Bradley (Rockwell Automation)
• Model: 1783-USP5T
• Product Type: Unmanaged Ethernet Switch
• Series: Stratix 2100
• Ethernet Ports: 5 × 10/100 Mbps Fast Ethernet Copper Ports
• Connector Type: RJ45
• Network Type: Industrial Ethernet / Layer 2 Switching
• Communication Speed: 10/100 Mbps
• Power Supply: SELV/PELV DC Power
• Mounting: DIN Rail Mount
• Enclosure Rating: IP30
• Dimensions:
  • Height: 114 mm
  • Width: 26 mm
  • Length: 70 mm
• Operating Temperature: -40°C to +75°C
• Configuration Type: Unmanaged (Plug-and-Play)

Advantages & Features

• Plug-and-play operation with no software configuration required
• Reliable industrial Ethernet communication
• Compact DIN rail mounting design saves cabinet space
• Supports fast 10/100 Mbps data transmission
• Wide operating temperature range for harsh environments
• IP30 industrial enclosure for control cabinet applications
• Compatible with Allen-Bradley automation systems
• Reduces installation and maintenance time

Applications

• Factory automation networks
• PLC and HMI communication
• CompactLogix / ControlLogix Ethernet systems
• Remote I/O communication
• Machine automation equipment
• Industrial production lines
• Process control systems

Important Notes

• Confirm Ethernet network compatibility before installation
• Use industrial-grade Ethernet cables for reliable communication
• Ensure correct DC power supply connection
• Avoid installation in environments with excessive moisture or dust
• This is an unmanaged switch and does not support advanced network configuration functions
